Design Engine, Gordan Murray Design Presentation

Gordon Murray DesignDesign DevelopmentNovember 2017

Design TeamDesign Engine Architects ArchitectsARUP Structures /Mechanical and ElectricalJackson Coles Quantity SurveyorHaydn Morris Planning Consultant

Ben Nicholson Concept Layout Courtyard Concept /Precedents St Catherines College Oxford



Site Layout

HQ Site Layout Concept VIP Parking Primary Access from A281 VIP RouteTowards Future DunsfordPark Development VIP EntranceKEY Visitor Route Approach Views Visible Building Frontage Delivery Route

Dunsfold Site Overall Development NOTE: The contractor is responsible for the checking of all site dimensions and levels. These should be checked prior to ordering of any components and before commencement of the works on site. All discrepancies should be brought to the immediate attention of the Contract Administrator. KEY: Site Access Boundary HORSHAM ROAD Site KEY: Grass Planting Groundcover Existing Trees Proposed Trees Buff Macadam Proposed Hedge Asphalt Proposed Water Permeable Paving N1o.2t.eDsToAhrinscohdtirtsaecwcatlisenagfrnoidsmtCotohbniessurdelrtaaadwntiinsngdco.ranwjuinngctsi,osnchweitdhualellsreanledvasnptecifications. A281 1:200 Scale Bar rev date Possible location for Technical GMD HQ and College or Offices Support FacilitiesPERIMETER ROAD

Dunsfold Site Option 1 NOTE: The contractor is responsible for the checking of all site dimensions and levels. These should be checked prior to ordering of any components and before commencement of the works on site. All Current GMD Site Locationdiscrepancies should be brought to the immediate attention of the Contract Administrator. KEY: KEY: SiteSiBteouAncdceasrys Boundary HORSHAM ROAD Grass Planting Groundcover Existing Trees Proposed Trees Buff Macadam Proposed Hedge Asphalt Proposed Water Permeable Paving N1o.2t.eDsToAhrnicsohdtitsreaccwatlsienafgrnoidsmCtotohbnisesudrlertaaawndtiisnngdc.roanwjuinngcst,iosnchweidthulaelsl raenledvsapnetcifications. A281 Building locations Location for new Possible location from Masterplan GMD HQ for Technical College or OfficesPERIMETER ROAD drawn chkd notes 1:500 @scaAle 1 rev date ProposeddaSteeofporigtien mber 2017MasterPlan -revision draPwrinog tpitleosed Site PLANNINGproGjecot tirtlcedlieGonDt noCurMrdnasounfnrolrelaMdigyuAhHr,erQSaroyudrDrreeoysmigen, 1710-P100drawing reference new status Arrival Road

Dunsfold Site Option 2 Relocation of GMD Site KEY: SiteSiBteouAncdceasrys Boundary Grass Planting Groundcover Existing Trees Proposed Trees Buff Macadam Proposed Hedge Asphalt Proposed Water Permeable Paving N1o.2t.eDsToAhrnicsohdtitsreaccwatlsienafgrnoidsmCtotohbnisesudrlertaaawndtiisnngdc.roanwjuinngcst,iosnchweidthulaelsl raenledvsapnetcifications. Possible location Prominent for Technical corner siteBuilding locationsfrom Masterplan Location for new drawn chkd GMD HQ notes 1:500 @scaAle 1 rev date daSteeofporigtien mber 2017 Master Plan -revision draPwrinog tpitleosed Site PLANNINGproGjecot tirtlcedlieGonDt noCurMrdnasounfnrolrelaMdigyuAhHr,erQSaroyudrDrreeoysmigen, status 1710-P100drawing reference Proposed new Arrival Road Proposed new Offices

KEY: Site Boundary Site Access Boundary Existing Trees Grass Proposed Trees Groundcover Planting Proposed Hedge Buff Macadam Proposed Water Asphalt Permeable PavingNotes1. Do not scale from this drawing.2. This drawing is to be read in conjunction with all relevant Architects and Consultants drawings, schedules and specifications.1:200 Scale Barrev date notes drawn chkdproject title date of origin scaleGordon Murray HQ September 2017 1:500 @ A1client drawing title revisionGordon Murray Design Proposed Site Master Plan -Dunsfold Aerodrome,Cranleigh, Surrey drawing referencestatus 1710-P100PLANNING

Concept Design

Site DevelopmentPhase 1a and 2a

ArrivalVisitors

AccessStaff parking

Arrival

AccessHGV, Vans etc

Design DevelopmentReception

Design DevelopmentConcept Section

Design Development

Design DevelopmentFacade

Design DevelopmentFacade

Design Development Structural section 4250 1150 4500 4500 4500 4500 10000OFFICES PRESENTATION ATRIA/STREET MEETING RM

Design Development Structural sectionCROSS SECTION OF HQ( PART ONLY)

Floor Plans Ground Floor Plan 4500 4500 4500 4500 4500 4500 4500 4500 4500 4500 4500 4500 4500 4500 4500 4500 4500 4500 4500 4500 4500 4500 4500 4500 4500 4500 4500 4500 Building D Vehicle Development/ R & D Building E Racing/ SVO Building F Car Company 4500 4500 Mezzanine over Mezzanine over 5000 Staff Entrance 4500 4500 5000 4500 4500 5000 4500 4500 4500 Sta4ff50E0ntrance 4500 5000 Possible extension 4500 5000 4500 7500 7500 7500 5000 7500 Staff Entrance 7500 7500 5000 7500 135 m2 9225 37 m2 87 m2 45 m2 44 m2 5000 LV/ HV transformer20 m2 LV 21 m2 34 m2 9225 22 m2 24 m2 14 m2 5000 4525 4525 5000 2700 2700 185 m2 185 m2 185 m2 4000 4500 4500 4000 3375 4500 4500 1620 5000 9800 11 m2 9800 IT 5000 50 m2 5150 5150 Stairs Kitchen 2300 5000 61m2 4525 4525 4500 Store 2200 Store 10 m2 35 m2 76 m2 133 m2 44 m2 Dining 2200 5000 174m2 Compressor Gas bottle 15 m2 44 m2 84 m2 4500 External Link 8 m2 4500 4500 1620 9225 dust extract 9225 9 m2 15 m2 5150 5000 2300 7500 5150 4500 7500 7500 7500 7500 7500 7500 4000 4500 4500 4000 Building B Diner & Executive Suite GIA 264 m2 4500 4500 4500 4500 4500 4500 4500 4500 4500 4500 4500 4500 4500 4500 4500 4500 4500 4500 4500 4500 4500 Meeting 18 m2 Room 5 Meeting 16 m2 Meeting 15 m2 4500 4500 4500 4500 4500 4500 Room 4 Room 3 18 m2 Staff Entrance Staff Entrance Escape Exit Meeting Room 2 Meeting Room 1 LV Switchroom HV/LV Transformer Bay Plant Plant Store Lobby 4500 4500 Showroom Display 92m2 Store 298 m258 m2 Clnrs 25m2 Cup. Staff WCs/ Shower Store Meeting Room 6 AWC 4500 Store Visitor Lounge/Display 30m2 4500 4 m2 3 m2 3 m2 6 m2 Presentation Theatre Display 18 m2 145 m2 24 m2 39 seats + 2 Accessible spots Deliveries AWC lift Store Coats Main HQ Entrance 4500 7 m2 150 m2 8 m2 3 m2 Staff WC 115 m2 Library 53 m2 BOH circulation 19 m2 3 m2 Reception 4500 Heritage Workshop & Prep Kitchen Staff WC 3 m2 5 no. Guest WCs 15 m2 Reception Office 7 m2 15 m2 7 m2 10 m2 9 m2 Store Pantry & Prep Store 4500 ICT Hub/Server 4500 Heritage Centre Display 12 m2 231 m2 1150 1150 Building A Headquarters GIA 1863 m2 4250 4250 4500 4500 4500 4500 4500 4500 4500 4500 4500 4500 4500 4500 4500 4500 4500 4500 4500 4500 4500 4500 4500 4500 4500 4500 4500 4500 4500 1 Proposed Level 00 GA Plan 1:250 Key KEY: -- 05.10.17 DRAFT ISSUE DE DE drawn chkd rev date notes

Floor Plans First Floor Plan 4500 4500 4500 4500 4500 4500 4500 4500 4500 4500 4500 4500 4500 4500 4500 4500 4500 4500 4500 4500 4500 4500 4500 4500 4500 4500 4500 4500 Building D Vehicle Development/ R & D Building E Racing/ SVO Building F Car Company 4500 4500 5000 4500 4500 5000 4500 4500 5000 4500 4500 4500 4500 5000 Possible extension 4500 4500 5000 Building C Design & Engineering GIA 1765 m2 4500 7500 7500 7500 5000 7500 7500 7500 7500 5000 Plant Design Three Design Two Design One 5000 47 m2 168 m2 168 m2 168 m2 9225 Cleaner/ WCs 9225 general St. 31 m2 13 m2 Lift 5000 4525 Seating 4525 Area 25 m2 5000 2700 Meeting/ Meeting/ Meeting/ 2700 office space office space office space 12 m2 12 m2 12 m2 4000 4500 4500 4000 3375 4500 4500 1620 5000 escape Build Unit Three below Roof light over Build Unit Two below Build Unit Two below Build Unit One below Build Unit One below stair two Build Unit Three below 9800 Model display 9800 area below WCs 5000 22 m2 5150 Kitchen 5150 45m2 Kitchen 2300 5000 17 m2 Stairs 4525 Engineering Studio 4525 4500 Boardroom 392 m2 121 m2 Meeting One 76m2 Executive Dining 20 m2 76m2 Executive escape 2200 stair one Meeting Two suite 27 m2 2200 5000 4500 4500 4500 1620 9225 9225 Circulation WC 2 no. 5150 5000 10m2 2300 Lift 5150 AWC 4500 7500 7500 7500 7500 7500 7500 7500 4000 4500 4500 4000 Building B Diner & Executive Suite 4500 4500 4500 GIA 292 m2 4500 4500 4500 4500 4500 4500 4500 4500 4500 4500 4500 4500 4500 4500 4500 4500 4500 4500 Building C void 4500 4500 4500 4500 4500 4500 Design/ Building B Engineering Diner & Executive Suite Meeting Room 8 25 m2 4500 void Plant Plant Games Room void void Bridge Link Chairman's Dressing 4500 26 m2 Suite Room 51 m2 3 m2 7 m2 rooflight over void Cleaners WC 3 m2 3 m2 Break Out 4500 Break Out Break Out 11m2 16m2 4500 AWC 21 m2 8 m2 Break Out 6 m2 4 m2 4 m2 3 m2 3 m2 Print Room Management Coats Store 16 m2 Management Coats Store Management Coats Store CEO & Meeting Room 7 35 no. seats + office manager Office 3 Chairman PA 25 m2 Office 8 Graphics, Press & PR, Marketing & Merchandising 36 no. Office 5 AWC lift 15 m2 7 m2 25 m2 CEO's 4500 20 m2 seats incl. Office Manager 115 m2 19 m2 IP & Licensing/ Admin 113 m2 Finance & Customer Accounts 35 no. seats + office manager WC Office 32 m2 4500 119m2 5 m2 3 no. WC Management void 9 m2 Office 1 4500 Management Management Management Combined ICT Hub/Server Management 19 m2 4500 Office 7 Office 6 Office 4 and USP Room 37 m2 Office 2 19 m2 19 m2 19 m2 25 m2 Store 1150 1150 Building A Headquarters GIA 1236 m2 4250 4250 4500 4500 4500 4500 4500 4500 4500 4500 4500 4500 4500 4500 4500 4500 4500 4500 4500 4500 4500 4500 4500 4500 4500 4500 4500 4500 4500 KeyKEY: -- 05.10.17 DRAFT ISSUE DE DE drawn chkd rev date notes

DUNSFOLD PARK MAIN ACCESS ROAD LANDSCAPED FRONTAGE BUILDING A COURTYARD & HEADQUARTERS DESIGN & EN SOUTH SITE BOUNDARY

Design Development Site SectionLDING C BUILDING D DELIVERY YARD & LOADING BAY GMD HQ SERVICE ROAD TEST TRACKEERING R & D / RIG TESTING NORTH SITE BOUNDARY

Headquarters Building

EXPLODED AXONOMETRIC OF HQ BUILDING

ApproachView from Main Road

ApproachPorte cochere

ReceptionMain HQ

Entrance AtriaMain HQ

Central CourtyardMain HQ and Refectory

Entrance AtriaFrom Courtyard

Approach

Design/Engineering Building

EXPLODED AXONOMETRIC OF DESIGN/ENGINEERING BUILDING

Design/EngineeringMain Entrance

NOTE: The contractor is responsible for the checking of all site dimensions and levels. These should be checked prior to ordering of any components and before commencement of the works on site. All discrepancies should be brought to the immediate attention of the Contract Administrator. Design/KEY: Engineering Build Units (Options) Build Unit Option 1 Build Unit Option 2 Build Unit Option 3 Sketch model views Sketch model views Sketch model viewsVoid Void Void Void Void Bridge over Bridge over Bridge overOffice/ Meeting Room Landing Office/ Meeting Room Build Unit Option 1 Build Unit Option 2 Parts Store Build Unit Option 3 First floor plan First floor plan (below) First floor planTrollies Plate Build Unit Option 1 Trollies Plate Trollies Plate Plate Ground floor plan Plate PlateBench Bench - 10.07.17 FIRST ISSUE DE DE Bench drawn chkd Bench rev date notes Bridge above Bench Bench Bridge aboveOffice Parts Store Stairs Office Stairs Office Stairs Parts Store Build Unit Option 2 Parts Store Build Unit Option 3 Ground floor plan Ground floor plan project title date of origin scale Gordon Murray HQ July 2017 1:100 @ A1 client drawing title revision Gordon Murray Design Building C Design & Engineering - Build Unit Option Studies status drawing reference INFORMATION 1714-SK0001

Design/EngineeringBuild bays

Programme

Gordon Murray HQ OPTION Traditional Contract Single Stage Tender( Risk through Planning Determination) June 2017Project Programme May 2017 Sept 2017 Jan 2018 May 2018 Sept 2018 Jan 2019 May 2019 Sept 2019 Jan 2020 May 2020Date: Revision: By: RIBA Stage 3-4 ConstructionDesign Team Apptmnt Planning 6 Months Allowance Permission for protractedPlanning Period Granted planning processRIBA Stage 2RIBA Stage 3 Lease runs out onRIBA Stage 4 current officesTender PeriodRIBA Stage 5 RIBA Stage 4 TenderConstruction Phase 1 developed at risk periodConstruction Phase 2 whilst in planning BoQRIBA Stage 6 Mobilisation Period Construct 11 months Start on Site Partial Construct 7 months Aug 2018 Hand over Aug 2019 Occupy May 2020

Gordon Murray HQ OPTION Traditional Contract with Pre-Construction of Engineering/Prototype Building Sept 2017Project Programme Hand overDate: Revision: By: Oct 2017 July 202030.08.17 Rev A RJ Jan 201822.09.17 Rev B RJ May 201827.09. 17 Rev C RJ July 2018 Sept 2018 Jan 2019 May 2019 Sept 2019 Jan 2020 May 2020 Aug 2020 Construction Pre Planning Planning Application Submission Permission GrantedPlanning Phase 1a Tender Lease runs out onRIBA Stage 2-3 period current officesRIBA Stage 4Tender Period BoQ Engineering/ProtoConstruction Phase 1 Building OccupyRIBA Stage 5 Construct 12 months July 2020RIBA Stage 3 Start on Site Hand overRIBA Stage 4 July 2018 June 2019Tender PeriodRIBA Stage 5 Phase 1b Tender periodConstruction Phase 2 BoQ Construct 18 months Start on Site Feb 2019

Gordon Murray HQ OPTION Traditional Contract with Pre-Construction of Engineering/Prototype Building Nov 2017Project Programme OccupyDate: Revision: By: Oct 2017 Dec 202030.08.17 Rev A RJ Jan 2018 Hand over22.09.17 Rev B RJ May 2018 Nov 202027.09. 17 Rev C RJ July 201827.11.17 Rev D RJ Sept 2018 Jan 2019 May 2019 Sept 2019 Jan 2020 Nov 2020 Construction Pre Planning Planning Application Submission Permission GrantedPlanning Phase 1a Tender Lease runs out onRIBA Stage 2-3 period current officesRIBA Stage 4Tender Period BoQ Engineering/Proto OccupyConstruction Phase 1 Building Nov 2019RIBA Stage 5 Construct 12 months Hand over Oct 2019RIBA Stage 3 Start on SiteRIBA Stage 4 Oct 2018Tender PeriodRIBA Stage 5 Phase 1b Tender periodConstruction Phase 2 BoQ Construct 18 months Start on Site May 2019

Gordon Murray HQ OPTION Traditional Single Phase Construction Nov 2017Project Programme Construction Oct 2017 Jan 2018 May 2018 July 2018 Sept 2018 Jan 2019 May 2019 Sept 2019 Jan 2020 July 2020 Pre Planning Planning Application Submission Permission GrantedPlanning Phase 1a/b TenderRIBA Stage 2-3 periodRIBA Stage 4 Extend lease toTender Period July 2020BoQConstruction Phase 1a/1b Construct 18 months Occupy July 2019RIBA Stage 5 Start on Site Hand over Oct 2018 June 2019
