Entertainment Applications INSTALLED & PORTABLE POWER DISTRIBUTION CATALOGPowerGATE™ PowerFLEX™ PowerPLUS™ Switches & Panels Cable Assemblies Installed Distribution Boxes ® PowerRACK™ Rolling Distribution Racks



Table of Contents Portable Power Control Solutions 6kW, 12kW, 24kW, Portable Dimmers ................................. 38 Permanently Installed Power Solutions Slim Dimmer Plus............................................................... 39 PowerGATE™ / PowerPlus™ / PCS TRIO™ Cable Accessories Power Distribution for Permanent Installations .................6-7 PowerPARTS™ Connector Strips and Outlet Boxes ....................................8-9 Company Switch............................................................10-11 Connector Parts .................................................................. 43 Emergency Lighting Transfer Switch (ELTS)........................ 12 400 Amp Power Input Panel................................................ 13 Cable Protectors PowerRAMP® Cable Assemblies and Extensions PowerFLEX™ Cable Crossovers, 45º Left and Right Turn Units and End Boots......................................................................... 42 EverGrip® LSC19 Cable Extensions .................................... 14 EverGrip® Break-Ins and Break-Outs................................... 15 Cable Repair and Retrofit Services EverGrip® Molded Quarter Turn and Socapex Lex Products EverGrip® Cable Retrofit Service Program ..... 44 Motor Control Cables ......................................................... 16 Lex Products Cable Repair Service Program....................... 45 Stage Pin Extensions .......................................................... 17 Feeder Cable, Snake Bite Adapters and Splitters................. 18 Resources powerCON Cable Assemblies ............................................. 19 Glossary of Portable Cord Types......................................... 87 Flat Convention Center Extension Cords............................. 19 Generator KVA Rating to NEMA Extensions ............................................................... 20 Amperage Conversion Chart ............................................... 88 E-String™ ........................................................................... 21 Wire Conversion Chart........................................................ 89 Data Cables....................................................................22-23 Notes .................................................................................. 89 Audio Cables ...................................................................... 24 Portable Power Distribution Boxes PowerHOUSE™ 20 Amp Quad Box with powerCON Input ............................ 25 20 Amp 3 Phase \"Doghouse\", Feed Thru ............................ 26 20 Amp \"Break Out Box\" to powerCON Connectors, Feed Thru........................................................ 27 Mountable \"Break Out Box\" and C-Clamp Mounting Options............................................................... 28 30 Amp 3 Phase Bento Box® to (6) 20 Amp Circuit, Feed Thru............................................................................ 29 60 & 100 Amp \"Lunch Box\" CineBox™ Stage Pin, Feed Thru............................................................................ 30 100 Amp Hollywood Box to (5) 20 Amp Circuits ................ 31 100 Amp 3 Phase Motion Picture Box with Tail Input.....32-33 200 Amp 3 Phase Motion Picture Box, Feed Thru............... 34 Load Master® Series ........................................................... 35 400 Amp 3 Phase Cam-Type Spider Box ............................ 36 400 Amp 3 Phase Motion Picture Box, Feed Thru............... 37

Quality. Innovation. Durability.Lex Products is a leading North American manufacturer of innovative power distribution and control systems for demandingmarkets, including entertainment, industrial and the military. Founded in 1989, the company specializes in products designedto withstand rough use and harsh environments. Headquartered in Connecticut, the company also has offices in California,Florida and Scotland.An industry pioneer in innovative power distribution applications, Lex Products introduced the use of rubber enclosures forpower distribution boxes to North America. The company also instituted new molding technologies and applications for cableassemblies, enabling the development of products of unprecedented durability.All products are subjected to rigorous testing and designed to meet and exceed the strictest safety codes. Lex Productsmanufactures a full range of portable and permanent power distribution solutions,including:• PowerHOUSE™ Portable Distribution Boxes.• PowerFLEX™ Cable Assemblies• PowerGATE™ Power Switches and Input Panels• PowerPARTS™ Wiring Devices• Power Control Solutions• PowerRACK™ Enclosed Rack Mount Power Distribution• LuxCommander® Portable Work Lights• PowerRAMP® Cable ProtectorsLex Products can also develop comprehensive custom solutions to meet specific power distribution requirements.To learn more about Lex Products, please visit www.lexproducts.com.

Our Panel to Plug Philosophy...Lex Products has you covered from “Panel to Plug” with over 25 years of innovation in the entertainment market developingtechnologies used by studios, theatres, concerts, film sets and more.Our portable power distribution boxes, company switches, cable assemblies, connectors, cable ramp protectors and other variousproducts deliver the power to a wide variety of entertainment devices and fixtures. 43 5 2 4 14 5 5 4 41) Power Control Solutions PCS TRIO™ 4) PowerPLUS™ Connector Strip,2) PowerGATE™ Emergency Outlet Boxes and Floor Pocket Lighting Transfer Switch 5) PowerFLEX™ Cable Assemblies3) PowerGATE™ Company Switch

WE DELIVER THE POWERTMPCS TRIOTMPower Control Solutions Power control for the full range of lighting, audio, and video... RE-IMAGINED!Catalog Number: Features & Benefits:4 Module Chamber (PCS-I-A-MC-04) • Deliver power to a wide range of devices in a single panel8 Module Chamber (PCS-I-A-MC-08)16 Module Chamber (PCS-I-A-MC-16) • Modules connect dimmers, single pole, and double pole relaysChamber Controller (PCS-I-CC) to all phases of powerDescription: • Integrate easily with other power control and management devicesWhether your project requires power management of LEDs, movinglights and incandescent lights, projection screens, powered • Simplify lighting installations with less cabling and conduitspeakers or other appropriate equipment the revolutionary, patent-pending design of PCS TRIO™ enables power control over the • Supports the most popular control protocols: DMX-512A,widest equipment range. RDM, E1.31 sACN and Art-NetThe ability to consolidate single and double pole relays as well asdimmers into one panel has never been accomplished…until now! 6

WE DELIVER THE POWERTMPCS TRIOTM Modules PowerHOUSE™Power Control Solutions Portable Distribution BoxesRelay and Dimmer ModulesThe following modules include over-temperature sensing on a per module basis. Relays are mechanically latching, open-air type rated for500,000 cycles. All relay circuits possess zero-cross detection for relay trigger timing extending component life and maintain last state(open or closed) until signaled or manually manipulated. Dimmers are SCR, forward phasing with 350µs ruse time choices.Single Pole Relay/Double Pole • One Single Pole Relay rated for 120V 20A and one Double Pole Relay circuit rated for 240V 20APCS-A-MD-R2R • Three Single Pole Relay Circuits each rated for 120V 20ATriple Single Pole • One SCR Dimmer Circuit rated for 120V 20A and one Double Pole Relay CircuitPCS-A-MD-RRR rated for 240V 20ASingle Dimmer/Double PolePCS-A-MD-R2RSingle Dimmer/Dual Single Pole • One SCR Dimmer Circuit and two Single Pole Relay Circuits each rated for 120V 20APCS-A-MD-DRRTriple Dimmer • Three SCR Dimmer Circuits each rated for 120V 20A per circuitPCS-A-MD-DDDAdditional Modules • Plenum Modules occupy unpopulated Module Chamber slots and are critical to thePlenum Module safety, signal and air flow integrity of the systemPCS-A-MD-PPPAccesories • A wall-mounted device that converts digital signals into 16 channels of analog control voltageDigital to 0-10V DCDemultiplexer • Works in concert with PCS TRIO™ relays for the control of fully isolated LED fixtures requiring mains switching and 0-10V DC dimming as well as Mark VII type electronic PCS-I-DEMULT-ETHER fluorescent ballasts PCS-I-DEMULT-RJ485 Custom configurations, individual connectors and interconnecting cable assemblies available. 7

WE DELIVER THE POWERTM PowerPLUS™Connector Strips / Outlet Boxes Installed Distribution BoxesExtruded Aluminum Raceway TYPE 1 IndoorDescription: Features & Benefits:Custom built connector strips, wall mounts, and floor boxes to the • Wide range of connector types to suit most applicationsexact specifications of each installation. • Aluminum extrusion is inherently rustproof for longer life andCustom PowerPLUSTM distribution box options include: better appearance • Rigid extrusion cannot bend or flex• Length of the connector strip • Data option provides an integrated data and power distribution• Number and type of outlets, including 20 Amp stage pin, 20 Amp solution locking and 20 Amp Edison receptacles. Each receptacle option • Pre-wired assemblies make installation fast and easy can be configured as a flush mount or with a pigtail. Typical Applications:• Number of circuits Connector strips are used overhead to distribute power and DMX512• Method of mounting, options available include: single pipe to lighting fixtures in theaters and other places of assembly. Connector inline, double pipe inline, pipe grid and single pipe all-thread strips are often located on suspended pipes over stages and on pipes and catwalks over the audience.• DMX512 is available as an option to provide an integrated data and power distribution solution Ordering Information: See next pageCustom configurations, individual connectors and interconnecting cable assemblies available. 8

WE DELIVER THE POWERTMPowerPLUSTM Ordering Information PowerPLUS™ Installed Distribution BoxesConnector Strips Ordering Information I - 32 AAExample part number: PP040-D16LI-32AACatalog number abbreviations and definitions:PP 040 - D 16 LLength in Circuit DMX: Connector Mounting:Feet Quantity I-DMX pass thru A = Flush(3 digits) (2 digits) N-None C = 18\" 12/3 SO pigtailConnector Strip Mounting: Feed End: OutputB = Single pipe inline (facing connectors) ConnectorD = Double pipe inline L = Left QuantityE = Pipe grid mount R = Right (2 digits)F = Single pipe all-thread Output Connector Type: A = 20 Amp stage pin B = 60 Amp stage pin C = NEMA 5-15 D = NEMA 5-20 G = NEMA L5-20Outlet Boxes Ordering InformationExample part number: PPS-2-ACatalog number abbreviations and definitions:PP S - 2 - A Output Output Connector Type: Connector A = 20 Amp stage pin Quantity B = 60 Amp stage pin (2 digits) C = NEMA 5-15Connector Strip Mounting: D = NEMA 5-20S = Surface G = NEMA L5-20R = RecessedP = Pipe mountW = Wall pocketF = Floor pocketCustom configurations, individual connectors and interconnecting cable assemblies available. 9

WE DELIVER THE POWERTMCompany Switch PowerGATE™Patented, UL Listed Access for Temporary Power Switches & Panels Application: • Theaters • Convention Centers • Studios • Theme Parks • Recreational Facilities TYPE 1 Indoor or Features & Benefits: TYPE 3R • PowerGATE™ Company Switch design accommodates both US Patent Cam-type or IEC 60309 pin & sleeve and lug outputs in one Numbers 7,136,278 wiring chamber, resulting in a compact design & 7,254,009 • Circuit breaker rated at 65,000 AIC (Amps Interrupting Capacity) to exceed requirements for installed dimmersCatalog Number: • Units feature an electronic trip circuit breaker that is 100%See Ordering Information tables on pages 12 rated, enabling continuous operation at maximum capacityDescription: • For enhanced safety, the access door to Cam-type or IEC 60309 pin & sleeve and lug connections is interlocked to theThe patented Lex Products PowerGATE™ Company Switch provides main breaker, which means the breaker can only be turned ona safe and convenient means of supplying access to temporary when the access door is closedpower. The space saving, metal enclosure provides both lug styleas well as IEC 60309 pin & sleeve or 16 Series Cam-type outputs • Power shuts off automatically when the access door isand is available in both beige and black finishes. Connections are opened, eliminating the ability to make or break a connectionprotected by a 100% rated electronic trip main breaker. Company under loadSwitches with Cam-type connections are available in 100, 200 and400 Amp ratings, with NEMA 1 and NEMA 3R rated enclosures and • Unique arrangement of both Cam-type or IEC 60309 pin &are cULus Listed. Company Switches with pin & sleeve connections sleeve and lug terminations enables both sets of cable toare available in 60 and 100 Amp ratings, in a NEMA 1 rated drape downward for lower profile when mounted against aenclosure and are cULus Listed. wall • Both Cam-type or IEC 60309 pin & sleeve and lug connections are behind the access door, helping to eliminate accidental disconnection, unauthorized access and/or tampering with connections • Circuit breakers and connection chamber housed behind gasketed door • Circuit breaker door allows for lockout/tagout and restricted access as needed • NEMA 3R Weather Resistant version available with Cam-type connections • The chassis ground can be isolated from the main ground for sensitive audio applications 10

WE DELIVER THE POWERTM PowerGATE™Company Switch with Cam-Type Outlets Switches & PanelsPatented, UL Listed Access for Temporary Power SIDE VIEW LUG OPENING FOR BARE END CABLE CAM TYPE FEMALE CONNECTOROrdering Information TYPE 1 Indoor or TYPE 3RCatalog Number(NEMA 1 Indoor) 400 AMP 200 AMP 100 AMP CS-400F-C6DS1 CS-200F-C6DS1 CS-100F-C6DS1 CS-400F-C6DB1 (reverse ground neutral) CS-200F-C6DB1 (reverse ground neutral) CS-100F-C6DB1 (reverse ground neutral)Catalog Number CS-400F-C6DS3 CS-200F-C6DS3 CS-100F-C6DS3(NEMA 3R Weather Resistant) CS-400F-C6DB3 (reverse ground neutral) CS-200F-C6DB3 (reverse ground neutral) CS-100F-C6DB3 (reverse ground neutral)Rating 400 Amp, 3 Phase, 120/208Y VAC 200 Amp, 3 Phase, 120/208Y VAC 100 Amp, 3 Phase, 120/208Y VACOvercurrent Protection 65,000 AIC Main Breaker 65,000 AIC Main Breaker 65,000 AIC Main BreakerOutput 100% Rated 100% Rated 100% RatedCabinet Finish Color (6) 16 Series Cam-type devices: (6) 16 Series Cam-type devices: (6) 16 Series Cam-type devices:Dimensions Black - Hot Black - Hot Black - Hot Blue - Hot Blue - Hot Blue - Hot Red - Hot Red - Hot Red - Hot (2) White - Neutral (2) White - Neutral (2) White - Neutral Green - Ground Green - Ground Green - Ground Beige or matte black powder coat Beige or matte black powder coat Beige or matte black powder coat For black finish, add suffix \"-BLK\" to For black finish, add suffix \"-BLK\" to For black finish, add suffix \"-BLK\" to catalog number catalog number catalog number 45.22\" H x 20.28\" W x 9.33\" D 37\" H x 20.28\" W x 9.33\" D 37\" H x 20.28\" W x 9.33\" DApproximate Weight 130 lbs. 123 lbs. 123 lbs.NOTES: For 5 Wire, replace 6 with 5 in catalog number 11

WE DELIVER THE POWERTM PowerGATE™Emergency Lighting Transfer Switch (ELTS) Switches & PanelsListed, Superior Fault Protection for Emergency Use TYPE 1 Indoor Features & Benefits:Catalog Number: • Complies with code requirements for UL Listed 1008 Emergency Lighting Transfer SwitchesDiscrete Feed (multiple 20 Amp): LELTS-XX-1Main Feed (single 120/208 VAC): LELTS-XX-3 • 65,000 Amp short circuit current rating provides superior faultXX= Number of 20 Amp circuits protectionDescription: • Electrically operated, mechanically held contactors switch both line and neutralThe Emergency Lighting Transfer Switch (ELTS) system switchespower from a normal source to an emergency source when a power • Five second switch time from normal power to standby poweroutage is detected. The ELTS provides a feature rich interface ensures quick transfer is made and accommodates standbythat monitors utility power input, has remote generator starting power sources startupcapabilities and is able to interface with most fire alarm systems. • One minute switch time from standby power to normal powerApplication: ensures that the normal power source is stableWhen a power loss occurs, it is critical that emergency lighting • Allows selected existing dimmed house light circuits to also besystems turn on to enable safe egress from the building. The used for emergency lighting, eliminating the need for dedicatedPowerGATE™ ELTS provides a cost effective, UL Listed 1008 transfer emergency circuits and fixturesswitch option that reduces the need for separate emergency lightingsystems. • Both discrete and main feed models available in multiple circuit configurationsCabinet Sizes2 Circuits 24\"H x 24\"W x 8\"D4-6 Circuits 30\"H x 24\"W x 8\"D8-10 Circuits 30\"H x 30\"W x 8\"D12-16 Circuits 36\"H x 30\"W x 8\"DConfigurations with up to 30 circuits are available. Contact Lex Products for details. 12

WE DELIVER THE POWERTM PowerGATE™400 Amp Power Input Panel Switches & PanelsTemporary Power Connection Point with Cam-type Connector Input TYPE 3R Features & Benefits:Catalog Number: • The PowerGATE™ Power Input Panel is a UL Listed, convenient and economical means of connecting emergency generatorPIP400-C5M-3F-BRB and PIP400-C5M-3F-BOY power to a building in conjunction with a transfer switchDescription: • Cables with 16 Series Cam-type connectors can connect directly to the inputs, saving crucial time in emergency situations400 Amp, 3 Phase, 4 Pole, 5 Wire, 120/208 VAC or 277/480 VACpermanently installed enclosure with Cam-type input, NEMA 3R • Cables drape downward to minimize profile against wallWeather Resistant. • Tamper proof design limits access to connected cables to helpApplication: prevent cables from being disconnected when door is closedThis panel provides a UL Listed and easy connection point for cables • Weather resistant construction for exterior use helps to ensurecoming from a portable generator when temporary power is required long lifedue to a power outage. The Power Input Panel is used in conjunctionwith a transfer switch. • Dead front panel covers all exposed electrical parts for added safety • Padlock hasp helps prevent unauthorized entry • Individual cable entry holes restrict access, reducing theftSpecifications & Ordering InformationCatalog Numbers PIP400-C5M-3F-BRB PIP400-C5M-3F-BOY 400 Amp Power Input Panel 277/480 VACDescription 400 Amp Power Input Panel 120/208 VAC 400 Amp, 3 Phase, 4 Pole, 5 Wire, 277/480 VAC (5) 16 Series Cam-type connectors in brown, orange, yellow,Rating 400 Amp, 3 Phase, 4 Pole, 5 Wire, 120/208 VAC white and greenConnector Input (5) 16 Series Cam-type connectors in blue, black, red, Lug terminals #2 AWG to 600MCM white and green Entire assembly is UL Listed, TYPE 3RConnector to Lug terminals #2 AWG to 600MCMBuilding Wiring Fiberglass, NEMA 3R Weather ResistantAgency Approval Entire assembly is UL Listed, TYPE 3R 30 ¾\"H x 21\"W x 10 ½\"D 58 lbs.Enclosure Material & Fiberglass, NEMA 3R Weather ResistantEnvironmental RatingOverall Dimensions 30 ¾\"H x 21\"W x 10 ½\"DApproximate Weight 58 lbs. Custom configurations, individual connectors and interconnecting cable assemblies available. 13

WE DELIVER THE POWERTMEverGrip® LSC19 Cable Extensions PowerHOUSE™Molded 6-Circuit Multi-Cable Extensions Portable Distribution Boxes Features & Benefits: • Thermoplastic resin premold creates a bond between the cable and connector for superior strain relief and secure + terminations • Pins and sockets cannot push back, extending life of the connector • Rugged construction helps prevent broken conductors and loose or damaged ground rings • Keyed design prevents misalignment of circuit conductors and unmateable or mismatched connections • Thermoplastic elastomer overmold absorbs impact and provides an insulated and secure gripping surface for easier mating and safe handling • Multi-cables carry 6-circuits of lighting power inside a single jacket, avoiding 6 individual runs of cable • Specially formulated thermoplastic rubber jacket provides exceptional flexibility and durability • Available in 12, 14 and 16 AWG to meet specific requirements • 14 conductor multi-cable offers two lower weight options when bonded grounds are accepted • \"Tempered spring\" female contacts maintain constant pin pressure to help ensure low resistance connections • Silver-plated brass contacts for high conductivity • All black design blends into scenery and is ideal for stage or studio lighting applicationsRating Male/Female Connector Cable Catalog No. 12/18 TPR EGME-1218-XX20 Amp*, 300 VAC Maximum (6-circuit) Molded Lex 6-circuit 12/14 TPR EGME-1214-XX 14/14 TPR EGME-1414-XX20 Amp*, 300 VAC Maximum (6-circuit) Ground Conductors Bonded Molded Lex 6-circuit 16/18 TPR EGME-1618-XX15 Amp*, 300 VAC Maximum (6-circuit) Ground Conductors Bonded Molded Lex 6-circuit5 Amp**, 300 VAC Maximum (6-circuit) Molded Lex 6-circuit++Add suffix WP for weatherproof cover on female connector.XX to specify cable length. Standard lengths are 5', 10', 15', 25', 50', 75', 100', 125', 150' and 200'. +See www.lexproducts.com for warranty details*Maximum when used with 50% diversity of load (in accordance with table NEC 520-44)**5 Amps simultaneously on all circuits AVAILABLE IN STANDARD CABLE ASSEMBLY Custom configurations, individual connectors and interconnecting cable assemblies available. 14

WE DELIVER THE POWERTMEverGrip® Break-Ins and Break-OutsMolded 6-Circuit Cable Assemblies Break-In (6) male 20 Amp stage pins to female LSC19 Features & Benefits: • Thermoplastic resin premold creates a bond between the cable and connector for superior strain relief and secure terminations • Pins and sockets cannot push back, extending the life of the connectors • Rugged construction helps prevent broken conductors and loose or damaged ground rings • Keyed design prevents misalignment of circuit conductors and unmateable or mismatched connections • Thermoplastic elastomer overmold absorbs impact and provides an insulated and secure gripping surface for easier mating and safe handling • Silver-plated brass contacts for high conductivity • Available with a variety of Edison, stage pin or NEMA connectors • All black design blends into scenery and is ideal for stage or studio lighting applications Break-Out male LSC19 to (6) female 15 Amp NEMA 5-15Break-InRating Male Connector Cable Female Connector Catalog No. Molded Lex LSC19 EGBI100-3-SP20 Amp*, 125 VAC (6) 20 Amp Stage Pins 12/3 SJOW-A, 3\" Molded Lex LSC19 EGBI100-3-51520 Amp*, 125 VAC (6) NEMA 5-15 Edison 12/3 SJOW-A, 3\" Molded Lex LSC19 EGBI100-3-L52020 Amp*, 125 VAC (6) NEMA L5-20 Locking 12/3 SJOW-A, 3\" Molded Lex LSC19 EGBI100-3-L62020 Amp*, 125 VAC (6) NEMA L6-20 Locking 12/3 SJOW-A, 3\"Break-OutRating Male Connector Cable Female Connector Catalog No. EGB0100-6-51515 Amp*, 125 VAC Molded Lex LSC19 12/3 SJOW-A, 6' (6) NEMA Edison 5-15 EGBO100-STG-515 EGBO100-6-SP15 Amp*, 125 VAC Molded Lex LSC19 12/3 SJOW-A (6) NEMA Edison 5-15, Staggered EGBO100-STG-SP EGBO100-6-L52020 Amp*, 125 VAC Molded Lex LSC19 12/3 SJOW-A, 6' (6) 20 Amp Stage Pins EGBO100-6-L62020 Amp*, 125 VAC Molded Lex LSC19 12/3 SJOW-A (6) 20 Amp Stage Pins, Staggered20 Amp*, 125 VAC Molded Lex LSC19 12/3 SJOW-A, 6' (6) NEMA L5-20 Locking20 Amp*, 125 VAC Molded Lex LSC19 12/3 SJOW-A, 6' (6) NEMA L6-20 LockingAdd suffix WP for weatherproof cover on female connector. Only available on break-ins.Custom lengths available. Contact a sales representative.*Maximum when used with 50% diversity of load (in accordance with table NEC 520-44). AVAILABLE IN STANDARD CABLE ASSEMBLY Custom configurations, individual connectors and interconnecting cable assemblies available. 15

WE DELIVER THE POWERTMEverGrip® Molded Motor Control Cable ExtensionsSocapex® and Quarter Turn Control Extensions for Hoists and MotorsDescription: Features & Benefits:Lex Products Patent Pending EverGrip® overmold technology • Thermoplastic material bonds the cable to the connectorprovides enhanced safety and durability for critical motor and to provide superior strain relief and maintain securehoist operations required in entertainment scenery and rigging terminationsapplications. EverGrip® connectors and extensions feature atwo-part molding process to help prevent internal damage and • Proprietary connector design prevents pins and contactsprovide exceptional strain relief that transfers pressure away from pushing back into housing, extending cable assemblyfrom the connectors. Lex Products EverGrip® molded motor lifecontrol cable extensions are available in 7 and 14 pin quarterturn configurations as well as a 7 pin Socapex® compatible • Proprietary connector construction encapsulates conductorsconfiguration. In 2011, the Lex Products’ EverGrip® molded 7 to prevent short circuits due to stray conductorsand 14 pin quarter turn motor control cables won a “Rock OurWorld” award for technology innovation from the entertainment • Oil resistant thermoplastic elastomer overmold absorbsindustry association PLASA. impact, protects internal conductors and provides an insulated gripping surface • Locking ring is overmolded for impact resistance and provides a firm gripping surface when mating and unmating connectors • Molded strain relief extends cable life • Supportive wire mesh bus drop cable grip transfers stress from suspended cables away from connectors • Connector arrows indicate proper mating alignmentSpecifications:Rating Configuration Cable Catalog No. EGME16/7-XX10 Amp, 250 VAC 7 pin quarter turn male and female overmolded connectors 16 AWG, 7 conductor SOOW EGME16/7-P14-XX EGME16/7-XX-SX10 Amp, 250 VAC 14 pin quarter turn male and female overmolded connectors 16 AWG, 7 conductor SOOW EGME14/7-XX-SX10 Amp, 250 VAC 7 pin Socapex male and female overmolded connectors 16 AWG, 7 conductor SOOW10 Amp, 250 VAC 7 pin Socapex male and female overmolded connectors Heavy-duty 14 AWG, 7 conductor SOOWXX to specify cable length +See www.lexproducts.com for warranty details AVAILABLE IN STANDARD CABLE ASSEMBLY Custom configurations, individual connectors and interconnecting cable assemblies available. 16

WE DELIVER THE POWERTMStage Pin Extensions20, 60 and 100 Amp Assemblies 100 Amp Stage Pin Extension Features & Benefits:20 Amp Stage Pin Extension • Banded extensions are made with single conductor type SC cable and are banded every 2 feet with heavy-duty type head shrink tubing • Extensions feature stage pin connectors machined from high temperature phenolic material • 60 and 100 Amp assemblies use double set screw terminals for secure terminations • Stage pin connectors are ETL ListedSpecifications:Rating Male Connector Cable Female Connector Catalog No. 100 Amp, 2 Pole, 3 Wire stage pin BE2000-XX100 Amp, 120 VAC 100 Amp, 2 Pole, 3 Wire (3) #4 AWG type SC 100 Amp, 2 Pole, 3 Wirestage pin BE206L-XX stage pin 100 Amp, 2 Pole, 3 Wire stage pin BE206L-XX-220 (2) #4 AWG type SC (1) #6 AWG type SC 60 Amp, 2 Pole, 3 Wire stage pin BE1000-XX100 Amp, 120 VAC 100 Amp, 2 Pole, 3 Wire green 60 Amp, 2 Pole, 3 Wire stage pin BE106L-XX stage pin (2) #4 AWG type SC (1) #6 AWG Type SC 20 Amp, 2 Pole, 3 Wire stage pin BE7000-XX green 20 Amp, 2 Pole, 3 Wire stage pin BE7000J-XX100 Amp, 250 VAC 100 Amp, 2 Pole, 3 Wire stage pin (3) #6 AWG type SC60 Amp, 120 VAC 60 Amp, 2 Pole, 3 Wire (2) #6 AWG type SC (1) #6 AWG type SC stage pin green 12/3 SOOW-A portable cord extra hard60 Amp, 120 VAC 60 Amp, 2 Pole, 3 Wire usage stage pin 12/3 SJOOW-A portable cord junior hard service20 Amp, 120 VAC 20 Amp, 2 Pole, 3 Wire stage pin20 Amp, 120 VAC 20 Amp, 2 Pole, 3 Wire stage pinXX to specify cable lengthStandard lengths: 25, 50 and 100 feet AVAILABLE IN EVERGRIP®The PinSaver™ Solution– Mates with Lex EverGrip® Molded Stage Pin Extensions, Group 5®, Bates®, Mole-Richardson® and Paladin® 100 Amp 125 Volt stage pin connectors– Rugged impact-resistant thermoset silicone rubber construction– Solid brass pin/contact design provides excellent conductivity– Amperage and voltage rating are “molded in” on both sides of adapter– Molded in thru-hole to conveniently fasten tie line for cable support Catalog Number:– Flammability - Meets UL 94 V0 material classification PS100125 Custom configurations, individual connectors and interconnecting cable assemblies available. 17

WE DELIVER THE POWERTMFeeder / Adapters / SplittersCam-Type ExtensionsRating Male Connector Cable Female Connector Catalog No.400 Amp, 600 VAC 16 Series Inline 4/0 AWG Type SC (Entertainment) 16 Series Inline FE6000-XX200 Amp, 600 VAC 16 Series Inline 2/0 AWG Type W (Industrial) 16 Series Inline FE500W-XX100 Amp, 600 VAC 16 Series Inline #2 AWG Type SC (Entertainment) 16 Series Inline FE3000-XX100 Amp, 600 VAC (5) 16 Series Inline #2 AWG Type SC (5) Wire Banded (5) 16 Series Inline FB305W-XXAdd suffix to indicate connector color: A=Black B=White C=Red D=Blue E=GreenXX to specify cable lengthSoft SiameseRating Male Cable Center Female Catalog Connector Section Connector No. 4/0 AWG Type SC Crimp with Y heat shrink boot (2) 16 Series Inline SS6000-C400 Amp, 600 VAC 16 Series Inline (Entertainment) Crimp with Y heat shrink boot (2) 16 Series Inline SS5000-C200 Amp, 600 VAC 16 Series Inline 2/0 AWG Type SC (Entertainment) Crimp with Y heat shrink boot (2) 16 Series Inline SS3000-C100 Amp, 600 VAC 16 Series Inline #2 AWG Type SC (Entertainment)Snake Bite Adapters / SplittersRating Male Connector Cable Female Connector Catalog No. #2 AWG Type SC, 2'100 Amp, 120 VAC (3) 16 Series Cam-type; black, white, #2 AWG Type SC, 2' Fused 100 Amp, 120 SB300F-125- green #2 AWG Type SC, 2' VAC, 2 Pole, 3 Wire FUS #2 AWG Type SC, 2' stage pin #2 AWG Type SC, 2'100 Amp, 120 VAC 100 Amp, 120 VAC, 2 Pole, 3 Wire #4 AWG Type SC (3) 16 Series Cam-type; SB300M-125100 Amp, 120 VAC stage pin #6 AWG Type SC black, white, green100 Amp, 250 VAC #6 AWG Type SC100 Amp, 250 VAC (3) 16 Series Cam-type; black, white, #6 AWG Type SC 100 Amp, 120 VAC, 2 SB300F-125100 Amp, 120 VAC green Pole, 3 Wire stage pin 100 Amp, 250 VAC, 2 Pole, 3 Wire (3) 16 Series Cam-type; SB300M-250 stage pin black, red, green (3) 16 Series Cam-type; black, red, 100 Amp, 250 VAC, 2 SB300F-250 green Pole, 3 Wire stage pin 100 Amp, 120 VAC, 2 Pole, 3 Wire (2) 100 Amp, 120 VAC, 2 SP100-100 stage pin Pole, 3 Wire stage pins100 Amp, 120 VAC 100 Amp, 120 VAC, 2 Pole, 3 Wire (2) 60 Amp, 120 VAC, 2 stage pin Pole, 3 Wire fused stage SP100-60-F pins100 Amp, 120 VAC 100 Amp, 120 VAC, 2 Pole, 3 Wire (2) 60 Amp, 120 VAC, 2 SP100-6060 Amp, 120 VAC stage pin Pole, 3 Wire stage pins 60 Amp, 120 VAC, 2 Pole, 3 Wire stage (2) 60 Amp, 120 VAC, 2 SP60-60 pin Pole, 3 Wire stage pinsCustom configurations, individual connectors and interconnecting cable assemblies available. 18

WE DELIVER THE POWERTM PowerHOUSE™powerCON Cable Assemblies Portable Distribution BoxesFor interconnecting LED lighting, portable speakers and intelligent lightingpowerCON Cable powerCON TRUE1 powerCON Feed Extensions Cable Extensions Thru AdaptersRating Power Input Cable Power Output Catalog No. 12/3 SJOOW Gray powerCON PE700J-XX-PCN20 Amp, 2 Pole, 3 Wire, 120 VAC Blue powerCON 12/3 SJOOW powerCON TRUE1 PE700J-XX-TRUE120 Amp, 120 VAC powerCON TRUE1XX to specify cable lengthStandard lengths are 25, 50, 75 and 100 feet.Fixture “Power In” Feed Thru Cable Catalog No.20 Amp Blue powerCON NEMA 5-15, 15 Amp, 120 VAC, male/female 12/3 SJTOW-A, Molded Y 3123J-515/PCN20 Amp Blue powerCON NEMA L5-20, 20 Amp, 120 VAC, male/female 12/3 SJTOW-A, Molded Y 3123J-L520/PCN20 Amp Blue powerCON 20 Amp, 120 VAC, stage pin, male/female 12/3 SJTOW-A, Molded Y 3123J-SP/PCNFlat Convention Center Extension CordsRating Length Gauge No. of Stranding Male Female Catalog No. Conductors Connector Connector15 Amp, 125 VAC 15 ft. 14 3 41/30 5-15P 5-15R 14G15FT15 Amp, 125 VAC 25 ft. 14 3 41/30 5-15P 5-15R 14G25FT15 Amp, 125 VAC 50 ft. 14 3 41/30 5-15P 5-15R 14G50FT15 Amp, 125 VAC 15 ft. 12 65/30 12G15FT15 Amp, 125 VAC 25 ft. 12 3 65/30 5-15P 5-15R 12G25FT15 Amp, 125 VAC 50 ft. 12 3 65/30 5-15P 5-15R 12G50FT 3 5-15P 5-15R Custom configurations, individual connectors and interconnecting cable assemblies available. 19

WE DELIVER THE POWERTMNEMA Extensions PowerHOUSE™ Portable Distribution Boxes NEMA wiring device extensions are made with extra hard usage (SOOW-A) or junior hard service (SJOOW-A) • 30 Amp, 3 Phase, 4 Pole, 5 Wire, 120/208 VAC extension (left) • 15 Amp, Single Phase, 2 Pole, 3 Wire, 120 VAC straight blade Edison extension (right)Rating Male Cable Female NEMA Catalog Connector Connector30 Amp, 3 Phase, 4 Pole, 5 Wire, 120/208 VAC HBL2811 10/5 SOOW-A HBL2813 Configuration No.20 Amp, 3 Phase, 4 Pole, 5 Wire, 120/208 VAC HBL2511 12/5 SOOW-A HBL251315 Amp, Single Phase, 2 Pole, 3 Wire, 120 VAC X515P 12/3 SOOW-A X515C L21-30 PE105-XX-L213015 Amp, Single Phase, 2 Pole, 3 Wire, 120 VAC X515P 12/3 SJOOW-A X515CWeatherproof Extensions L21-20 PE125-XX-L212030 Amp, 3 Phase, 4 Pole, 5 Wire, 120/208 VAC20 Amp, 3 Phase, 4 Pole, 5 Wire, 120/208 VAC 5-15 PE7000-XX-X51515 Amp, Single Phase, 2 Pole, 3 Wire, 120 VACXX to specify cable length 5-15 PE700J-XX-X515 28W81 10/5 SOOW-A 29W81 L21-30 PE105-XX-L2130W 26W81 12/5 SOOW-A 27W81 L21-20 PE125-XX-L2120W 14W47 12/3 SOOW-A 15W47 5-15 PE123-XX-515WCustom configurations, individual connectors and interconnecting cable assemblies available. 20

WE DELIVER THE POWERTME-String™15 Amp multiple receptacle extension cordCatalog Number: Description:50123W (white) / 50123B (black) E-String; 12/3 STW, NEMA 5-15 plug, (3) NEMA 5-15 receptacles; 25'8' 8' 6\" 8' 6\"50112WA (white) / 50112BA (black) E-String; 12/3 STW, NEMA 5-20 plug, (6) NEMA 5-15 receptacles; 50' 10' 10' 10' 10' 9' 1'50116BA (black) Orchestra String; 12/3 STW, NEMA 5-20 plug, (6) NEMA 5-15 receptacles; 23' 4\" 2' 4\" 4' 8\" 4' 8\" 4' 8\" 4' 8\" 2' 4\"59233B (black) Two Circuit, 220 VAC E-String; 12/4 STW, NEMA L14-20 plug/thru, (4) NEMA 5-15 receptacles; 33'8' 8' 8' 8' 1'Applications Recommended Version Weight Spacing Catalog No.Music stand lights in orchestra pits 12 AWG, (6) receptacles; 23' 4\"; BlackMeeting rooms for laptops, projectors, phones and 7 lbs. 4' 8\" 50116BAother equipment 12 AWG, (3) receptacles; 25'; BlackPhotography lighting 7 lbs. 8' 6\" 50123BDisplay booths in tents 12 AWG, (3) receptacles; 25'; BlackDisplay booths in convention centers 12 AWG, (6) receptacles; 50'; White 7 lbs. 8' 6\" 50123BScenery and other construction 12 AWG, (6) receptacles; 50'; Black 15 lbs. 10' 50112WAOutdoor events 12 AWG, (6) receptacles; 50'; Black 15 lbs. 10' 50112BA 12 AWG, 220 VAC, (4) receptacles; 33'; Black 15 lbs. 10' 50112BA 10 lbs. 8' 59233B Accessories Catalog Number: Description: 50301 (black) Adapter; NEMA 5-15, 15 Amp plug to NEMA 5-20, 20 Amp connector 50301W (white) Adapter; NEMA 5-15, 15 Amp plug to NEMA 5-20, 20 Amp connector 50201B (black) Tri-Tap; NEMA 5-15, 15 Amp male to (3) female receptacles 50201W (white) Tri-Tap; NEMA 5-15, 15 Amp male to (3) female receptacles Custom configurations, individual connectors and interconnecting cable assemblies available. 21

WE DELIVER THE POWERTM PowerHOUSE™Data Cables Portable Distribution BoxesDMX Extensions and Shielded XLR Data CablesType Male Connectors Cable Female Connector Catalog No. 3 Pin XLR Neutrik® (Black/Gold) DMX-3P-XX3 Pin XLR 3 Pin XLR Neutrik® (Black/Gold) 1 pair & shield, 22 AWG CC-4P-XX black polyurethane jacket 4 Pin XLR Neutrik® (Black/Gold) DMX-5P-XX RFU-XX-MMColor Changer 4 Pin XLR Neutrik® (Black/Gold) 1 pair & shield, 22 AWG (2) 14 5 Pin XLR Neutrik® (Black/Gold)& Color Blast AWG black polyurethane jacket 6 Pin Switchcraft® Compatible Neutrik® (Black/Gold)DMX 512 5 Pin XLR Neutrik® (Black/Gold) 2 pair & 2 shield, 22 AWG black polyurethane jacketRFU 6 Pin Switchcraft® Compatible 3 pair & shield, 22 AWG Neutrik® black polyurethane jacketXX to specify cable length4 Channel Cat5e Ethernet SnakeDescription Connectors Outside Diameter Channel Catalog No. Colors ES4RJ45-XX Each Channel Overall Black, Gray,4 channel Cat5e cable set with (4) RJ45 RJ45 with strain relief on each end .245\" .650\" Blue, Purpleconnectors with strain relief on each end RJ45 with heavy-duty Neutrik® .245\" .650\" Black, Gray, ES4EC-XX4 channel Cat5e cable set with (4) RJ45 Ethercon® cable connector Blue, Purpleconnectors shrouded with heavy-duty carriers on each endEthercon® cable connector carries on each .245\" .650\" Black, Gray, ES4RJ45-EC-XXend RJ45 connectors shrouded with Blue, Purple heavy-duty Ethercon® cable4 channel cable set with (4) RJ45 connectors connector carriers on one end andshrouded with heavy-duty Ethercon® cable RJ45 connectors with strain reliefconnector carriers on one end and (4) RJ45 on the otherconnectors with strain relief on the other endXX to specify cable length Custom configurations, individual connectors and interconnecting cable assemblies available. 22

WE DELIVER THE POWERTM PowerHOUSE™Data Cables Portable Distribution BoxesDMX Multi-CablesFor interconnecting LED lighting, portable speakers, Catalog Number:and intelligent lighting DMAX-9A-XXDataSNAKE™ DMX Multi-Cables - DMAX VersionMale/Female Connectors Cable(9) 5 pin XLR Neutrik® black/gold 5 pin male/ (2) twisted pair 22 AWG stranded tinned copper conductors with (2) Kevlar® strengthfemale connectors members for each circuitEach two pair shielded circuit is broken out of the multi-cable with heavy-duty thermoplastic heat-shrinkOverall Tour Grade 60 mil thermoplastic jacket, nominal O.D.: 0.68\", Weight: 230 lbs. per 1,000 feetXX to specify cable length(4) 5 Pin XLR, (1) 3 Pin XLR, (1) NEMA 5-15 Edison Extension Catalog Number: DS45P3P515-XXDataSNAKE™ DMX Multi-Cables - Front of House VersionType Qty Male/Female Connectors Cable15 Amp, 2 Pole, 4 Neutrik® (2) twisted pair 22 AWG stranded tinned copper conductors with (2) Kevlar®3 Wire, 120 VAC (black/gold) 5 Pin strength members, an overall braid shield and a polyurethane jacket.Intercom 1 Neutrik® (1) twisted pair 22 AWG stranded tinned copper conductor with Kevlar® strength (black/gold) 3 Pin member, shield and thermoplastic jacket.AC Power Circuit 1 Hubbell (all black) (3) 12 AWG stranded tinned copper with 105° C rated PVC jacket. Overall thermoplastic jacket industrial grade installed to break-out point.Overall Tour Grade 60 mil thermoplastic jacket, nominal O.D.: 0.780\", Weight: 350 lbs. per 1,000 feetXX to specify cable length Custom configurations, individual connectors and interconnecting cable assemblies available. 23

WE DELIVER THE POWERTMAudio Cables PowerHOUSE™ Portable Distribution Boxes XLR SnakesCatalog Item Male Cable FemaleNumber Description Connector ConnectorLPA-XLR-8PR-xxx Lex Pro Audio 3-Pin XLR Lex Pro Audio 8 Pair 3-Pin XLR 8 Pair XLR Cable Snake CableLPA-XLR-12PR-xxx Lex Pro Audio 3-Pin XLR Lex Pro Audio 12 Pair Snake 3-Pin XLR 12 Pair XLR Cable CableLPA-XLR-20PR-xxx Lex Pro Audio 3-Pin XLR Lex Pro Audio 20 Pair Snake 3-Pin XLR 20 Pair XLR Cable Cablexxx Indicates Cable Length Standard lengths 5’, 10’, 15’, 25’, 50’, 75’, 100’ & 150’. Custom lengths available 8-Pair XLR Snake XLR and TRS Cables and Adapters 3 Pin XLR Cable 4 Pin SpeakonCatalog Item A Cable BNumber Description Connector Connector 8 Pin CACOM Lex Pro Audio 20/2LPA-XLR-20/2-xxx Lex Pro Audio XLRM-F 20/2 3-Pin XLRM Microphone Cable 3-Pin XLRF Cable Lex Pro Audio 20/2LPA-XLRMTRS-20/2-xxx 3-Pin XLRF Microphone Cable 1/4\" TRS Plug Lex Pro Audio XLRF-TRSLPA-XLRFTRS-20/2-xxx 20/2 CableLPA-TRS-20/2-xxx Lex Pro Audio XLRM-TRS 3-Pin XLRM Lex Pro Audio 20/2 1/4” TRS Plug 20/2 Cable Microphone Cablexxx Indicates Cable Length Lex Pro Audio TRS 1/4\" TRS Plug Lex Pro Audio 20/2 1/4\" TRS Plug 20/2 Cable Microphone Cable Standard lengths 5’, 10’, 15’, 25’, 50’, 75’ & 100’. Custom lengths available Speaker CablesCatalog Item Male Cable FemaleNumber Description Connector Connector Lex Pro AudioLPA-SPK12/2-1/4-xxx Lex Pro Audio Jumbo 1/4\" 1/4\" Jumbo Plug 12/2 Speaker Cable 1/4\" Jumbo Plug Speaker CableLPA-SPK12/2-xxx Lex Pro Audio NL4 Speaker 4-PIn Lex Pro Audio 4-PinLPA-SPK12/4-xxx 12/2 Speaker Cable speakCONLPA-SPK12/8-xxx Cable speakCONLPA-SPK12/8-C8-xxx Lex Pro Audio 4-Pin Lex Pro Audio NL4 Speaker 4-Pin 12/4 Speaker Cable speakCON Cable speakCON Lex Pro Audio 8-Pin 12/8 Speaker Cable speakCON Lex Pro Audio NL8 Speaker 8-Pin Cable speakCON Lex Pro Audio 8-Pin 12/8 Speaker Cable CACOM Lex Pro Audio CA-COM8 8-Pin Speaker Cable CACOMxxx Indicates Cable Length Standard lengths 3’, 5’, 10’, 15’, 25’, 50’, 75’ & 100’. Custom lengths available Custom configurations, individual connectors and interconnecting cable assemblies available. 24

WE DELIVER THE POWERTM PowerHOUSE™20 Amp Quad Box with powerCON Input to Edisons, Feed Thru Portable Distribution BoxesCatalog Number: DB20PC-SBPC Specifications:Description: Rating: 20 Amp, Single Phase (H,N,G), 2 Pole, 3 Wire, 120 VAC Environmental Rating: NEMA 1 Indoor20 Amp, Single Phase, 2 Pole, 3 Wire, 120 VAC, Quad Box Input: (1) 20 Amp, 2 Pole, 3 Wire, 120 VAC, powerCON inletEnclosure, powerCON inlet to (2) NEMA 5-20, 20 Amp duplex Output: (2) NEMA 5-20, 20 Amp, 2 Pole, 3 Wire, 120 VACreceptacles, Feed Thru, NEMA 1 Indoor duplex receptacles Feed Thru: (1) 20 Amp, 2 Pole, 3 Wire, 120 VAC, powerCONApplication: outlet Overcurrent Protection: NoneThis extremely versatile box is used for placing convenience Enclosure Type: Quad Boxreceptacles exactly where they are needed. This box enables the Dimensions: 4.7\"L x 2.5\"W x 4.2\"Huser to create receptacle stringers using extensions of various Weight: 1.5 lbs.lengths.Features & Benefits:• Heavy-duty molded rubber enclosure is fully insulated and resistant to shock, impact and corrosion• Compact and convenient way to place 20 Amp duplex receptacles where they are needed• Feed thru option allows multiple boxes to be placed along the same feedCustom configurations, individual connectors and interconnecting cable assemblies available. 25

WE DELIVER THE POWERTM PowerHOUSE™20 Amp “Doghouse”, Feed Thru Portable Distribution BoxesBento Box® TYPE 1 Indoor Features & Benefits:Catalog Number: BNZA2-A3-6 • Stackable and compact for easy storage • Heavy-duty extruded engineered theromplastic enclosureDescription: is electrically insulated and resistant to shock, impact and20 Amp, 3 Phase, 4 Pole, 5 Wire, 120/208Y VAC, Bento corrosionEnclosure, NEMA L21-20, 20 Amp inlet to (3) NEMA 5-20, 20 • Duplex receptacles are color coded for phase identificationAmp color-coded duplex receptacles, Feed Thru, NEMA 1 Indoor • End plate grips for easy handling in tight spacesApplication: • Feed thru feature allows multiple boxes to be placed along the same feedThe Doghouse is ideal for trade shows and exhibitions where alarge number of convenience receptacles are needed over a wide Specifications:area. The feed thru feature allows multiple boxes to be placedalong a single feed so that receptacles can be easily accessed Rating: 20 Amp, 3 Phase (H,H,H,N,G), 4 Pole, 5 Wire,wherever needed. Doghouses are also popular in live event and 120/208Y VACaudio applications where multiple amplifiers, speakers and other Environmental Rating: NEMA 1 Indooraudio components require power while positioned on a stage orother location. Input: (1) NEMA L21-20, 20 Amp, 3 Phase, 4 Pole, 5 Wire, 120/208Y VAC inlet Output: (3) NEMA 5-20, 20 Amp, Single Phase, 2 Pole, 3 Wire, 120 VAC color-coded duplex receptacles Feed Thru: (1) NEMA L21-20, 20 Amp, 3 Phase, 4 Pole, 5 Wire, 120/208Y VAC locking receptacle Overcurrent Protection: None Enclosure Type: Bento Dimensions: 6\"L x 7.6\"W x 5.6\"H Weight: 4 lbs.Custom configurations, individual connectors and interconnecting cable assemblies available. 26

WE DELIVER THE POWERTM PowerHOUSE™20 Amp “Break Out Box” to powerCON Connectors, Feed Thru Portable Distribution BoxesBento Box®Catalog Number: Features & Benefits:Standard model (top): BNZJ2-6M • Provides power for LED lights that use powerCON plugsMountable C-clamp model (bottom): BNZJ2-6M-CLP • Optional model available that enables easy vertical orFor ordering information on boxes and hardware, see horizontal mounting with C-clamp (see page 28 for details)page 28. • Heavy-duty extruded engineered thermoplastic enclosureDescription: is electrically insulated and resistant to shock, impact and corrosion20 Amps per circuit, 6-circuit, Break Out Box, Bento Enclosure, • Feed thru feature allows multiple boxes to be placed alongLSC19 male panel mount to (6) 20 Amp powerCON Connectors, the same feedFeed Thru, NEMA 1 Indoor. Additional model available with • End plate grips for easy handling in tight spaces, andmounting holes on a metal handle and on the back to allow collapsible handle available on standard modelvertical or horizontal mounting on a truss or pole. • Stackable and compact for easy storageApplication: Specifications:Breaks an industry standard 6-circuit lighting cable into 20 Amp Rating: 20 Amp, 6-circuit, 120 VACpowerCON connections for powering LED lights. The feed thru Environmental Rating: NEMA 1 Indoorfeature allows multiple boxes to be placed along the same feed. Input: (1) 20 Amps per circuit, 6-circuit, 120 VAC, LSC19 male panel mount Output: (6) 20 Amp powerCON receptacles Feed Thru: (1) 20 Amps per circuit, 6-circuit, 120 VAC, LSC19 female panel mount receptacle Overcurrent Protection: None Enclosure Type: Bento Dimensions: 11.5\"L x 5.9\"W x 7.6\"H Weight: 6 lbs.Custom configurations, individual connectors and interconnecting cable assemblies available. 27

WE DELIVER THE POWERTM PowerHOUSE™Mountable \"Break Out Box\" and C-Clamp Mounting Options Portable Distribution BoxesBento Box® Ordering Standard C-Clamp With Thread Adapter Information for Horizontal Mounting for Vertical MountingStandard Break Out Box: BNZJ3-Z1.Mountable Break Out Box: BNZJ3-Z1-CLPMounting holes on a metal handle and on the back.C-Clamp Hardware (Sold Separately): GET-A-GRIPOptional thread adapter that enables horizontal mounting, add part number04-160-A11.Standard Break Out Box: BNZJ2-Z3.Mountable Break Out Box: BNZJ2-Z3-CLPMounting holes on a metal handle and on the back.C-Clamp Hardware (Sold Separately): GET-A-GRIPOptional thread adapter that enables horizontal mounting, add part number04-160-A11.Standard Break Out Box: BNZJ2-6M.Mountable Break Out Box: BNZJ2-6M-CLPMounting holes on a metal handle and on the back.C-Clamp Hardware (Sold Separately): GET-A-GRIPOptional thread adapter that enables horizontal mounting, add part number04-160-A11.Accessories (sold separately):Part Number Description ImageGET-A-GRIP C-clamp, aluminum black04-160-A11 C-clamp, thread adapter to 1/4\"-20 thread for horizontal mounting Custom configurations, individual connectors and interconnecting cable assemblies available. 28

WE DELIVER THE POWERTM PowerHOUSE™30 Amp 3 Phase Bento Box® to (6) 20 Amp Circuits, Feed Thru Portable Distribution BoxesBento Box® TYPE 1 Indoor Features & Benefits:Catalog Number: BNB2-3B • Hydraulic magnetic breakers help prevent nuisance tripping at higher temperaturesDescription: • Stackable and compact for easy storage30 Amp, 3 Phase, 4 Pole, 5 Wire, 120/208Y VAC, BentoEnclosure, NEMA L21-30, 30 Amp inlet to (3) NEMA 5-20, 20 • Heavy-duty extruded engineered theromplastic enclosureAmp color-coded duplex receptacles split wired for (6) 20 Amp is electrically insulated and resistant to shock, impact andcircuits, Feed Thru, NEMA 1 Indoor corrosionApplication: • Circuit breakers are mounted flush for easy access and numbered for easy circuit identificationFed from 30 Amp power, this compact unit provides 20 Ampduplex receptacles for lights, effects, audio equipment and tools • Collapsible handle and end plate grips for easy handlingfor a wide range of applications. The feed thru feature allows in tight spacesmultiple boxes to be placed along the same feed. • Feed thru feature allows multiple boxes to be placed along the same feed Specifications: Rating: 30 Amp, 3 Phase (H,H,H,N,G), 4 Pole, 5 Wire, 120/208Y VAC Environmental Rating: NEMA 1 Indoor Input: (1) NEMA L21-30, 30 Amp, 3 Phase, 4 Pole, 5 Wire, 120/208Y VAC inlet Output: (3) NEMA 5-20, 20 Amp, Single Phase, 2 Pole, 3 Wire, 120 VAC color-coded duplex receptacles split wired for (6) 20 Amp circuits Feed Thru: (1) NEMA L21-30, 30 Amp, 3 Phase, 4 Pole, 5 Wire 120/208Y VAC receptacle Overcurrent Protection: (6) 20 Amp hydraulic magnetic branch-rated circuit breakers Enclosure Type: Bento Dimensions: 11.5\"L x 5.9\"W x 7.6\"H Weight: 6.5 lbsCustom configurations, individual connectors and interconnecting cable assemblies available. 29

WE DELIVER THE POWERTM60 & 100 Amp, CineBoxTM Stage Pin Feed Thru PowerHOUSE™Lunch Box Portable Distribution Boxes Features & Benefits: • Stackable compact design for easy storage and portability • Heavy-duty rubber enclosure is electrically insulated and resistant to shock, impact and corrosion • Breakers are mounted flush for easy access and circuit identification • Hydraulic magnetic breakers will not nuisance trip at higher temperatures • Bright, color coded receptacles easily identify the box rating and increase visibility in low-light situations • Optional threaded insert on the back provides easy mounting with C-clamp* TYPE 1 Indoor Markets Served:Typical Application: Film, Motion Picture and Television ProductionFed from larger power sources, this compact distribution unit pro-vides 5-20 duplex receptacles for smaller lights and related equip-ment. The feed thru feature allows multiple boxes on the same feed.Part Number PH060B1-NDB-13CC PH100B1-NDC-15CCRating 100 Amp, Single Phase, 2 Pole, 3 Wire (H,N,G), 60 Amp, Single Phase, 2 Pole, 3 Wire (H,N,G), 120 VAC, 60 Hz 120 VAC, 60 HzEnvironmental Rating NEMA 1 Indoor NEMA 1 IndoorInput (1) 100 Amp, Single Phase, 2 Pole, 3 Wire, 120 VAC, stage pin inlet (1) 60 Amp, Single Phase, 2 Pole, 3 Wire, 120 VAC, stage pin inletOutput (5) NEMA 5-20, 20 Amp, Single Phase, 2 Pole, 3 Wire, 120 VAC, (3) NEMA 5-20, 20 Amp, Single Phase, 2 Pole, 3 Wire, 120 VAC, duplexFeed Thru duplex receptacles receptacles (1) 100 Amp, Single Phase, 2 Pole, 3 Wire, 120 VAC, stage pin (1) 60 Amp, Single Phase, 2 Pole, 3 Wire, 120 VAC, stage pin receptacle receptacleOvercurrent Protection (5) 20 Amp hydraulic magnetic 100% branch-rated circuit breakers (3) 20 Amp hydraulic magnetic 100% branch-rated circuit breakersDimensions 9.0”W x 9.0”L x 6.38”D 9.0”W x 9.0”L x 6.38”DWeight 11.0 lbs 9.5 lbs* Add “-TI” after part number for optional threaded insert Custom configurations, individual connectors and interconnecting cable assemblies available. 30

WE DELIVER THE POWERTM PowerHOUSE™100 Amp “Hollywood Box” to (5) 20 Amp Circuits Portable Distribution BoxesBento Box® TYPE 1 Indoor Features & Benefits:Catalog Number: BNF3-1A2B-10.5 • Hydraulic magnetic breakers help prevent nuisance tripping at higher temperaturesDescription: • Stackable and compact for easy storage100 Amp, Single Phase, 2 Pole, 3 Wire, 120 VAC, BentoEnclosure, stage pin plug on 12 inch type SC cable tail to (3) • Heavy-duty extruded engineered theromplastic enclosureNEMA 5-20, 20 Amp duplex receptacles split wired for (5) 20 is electrically insulated and resistant to shock, impact andAmp circuits, NEMA 1 Indoor. corrosionAvailable in panel mount style. • Circuit breakers are mounted flush for easy access and numbered for easy circuit identificationApplication: • Collapsible handle and end plate grips for easy handling inThis compact unit provides convenient 20 Amp duplex tight spacesreceptacles to power lights on motion picture and television sets. Specifications: Rating: 100 Amp, Single Phase (H,N,G), 2 Pole, 3 Wire, 120 VAC Environmental Rating: NEMA 1 Indoor Input: (1) 100 Amp, Single Phase, 2 Pole, 3 Wire, 120 VAC stage pin plug on 12 inch type SC cable tail Output: (3) NEMA 5-20, 20 Amp, Single Phase, 2 Pole, 3 Wire, 120 VAC, duplex receptacles split wired for (5) 20 Amp circuits Feed Thru: None Overcurrent Protection: (5) 20 Amp hydraulic magnetic branch-rated circuit breakers Enclosure Type: Bento Dimensions: 10.5\"L x 5.9\"W x 7.6\"H Weight: 7.8 lbsCustom configurations, individual connectors and interconnecting cable assemblies available. 31

WE DELIVER THE POWERTM PowerHOUSE™100 Amp 3 Phase Motion Picture Box with Tail Input Portable Distribution BoxesAlso known as the 300 Amp Box in the Film Industry TYPE 1 Indoor Application:Catalog Number: DBS100DT-B4BI2 This box provides power distribution for film or video productions, and powers 10K or 12K lighting fixtures. It also(for other configurations, see table below) provides convenience power from NEMA 5-20 duplex receptacles.Description: Features & Benefits:100 Amp, 3 Phase, 4 Pole, 5 Wire, 120/208Y VAC, Pagoda Jr. • Provides 100 Amp stage pin receptacles for powering lightsEnclosure, (1) set of (5) 16 Series Cam-type color-coded plugs and duplex receptacles for convenience poweron 18 inch #4 AWG type SC tails (available in reverse ground andneutral configuration) to (3) 100 Amp stage pin receptacles and • Heavy-duty molded rubber enclosure is fully insulated and(3) NEMA 5-20, 20 Amp duplex receptacles, NEMA 1 Indoor resistant to shock, impact and corrosion • Circuit breakers are mounted under hinged lid for enhanced protection • Stackable and compact for easy storage and convenient portability • Elevated base keeps receptacles above ground level • Reverse neutral and ground options help prevent mis-mating for enhanced safetySpecifications & Ordering Information DBS100DT-B4BI2-RGNCatalog Number DBS100DT-B4BI2 100 Amp, 3 Phase (H,H,H Reverse N, Reverse G), 4 Pole, 5 Wire, 120/208Y VACRating 100 Amp, 3 Phase (H,H,H,N,G), 4 Pole, 5 Wire, 120/208Y VAC NEMA 1 IndoorEnvironmental NEMA 1 IndoorRating (1) set of (5)16 Series Cam-type color-coded plugs on 18 inch (1) set of (5) 16 Series Cam-type color-coded plugs on 18 inch #4 AWG Type SC tails with reverse neutral and groundInput #4 AWG type SC tails (3) 100 Amp, 2 Pole, 3 Wire, 120 VAC, stage pin receptaclesOutput (3) 100 Amp, 2 Pole, 3 Wire, 120 VAC, stage pin receptacles (3) NEMA 5-20, 20 Amp, 2 Pole, 3 Wire, 120 VAC, duplex (3) NEMA 5-20, 20 Amp, 2 Pole, 3 Wire, 120 VAC, duplexFeed Thru receptaclesOvercurrent receptacles NoneProtection None (3) 100 Amp, Single Pole branch-rated circuit breakersEnclosure Type (3) 100 Amp, Single Pole branch-rated circuit breakers (3) 20 Amp, Single Pole branch-rated circuit breakersDimensions (3) 20 Amp, Single Pole branch-rated circuit breakers Pagoda Jr.Approximate Pagoda Jr. 11.38\"L x 11.38\"W x 11.32\"HWeight 11.38\"L x 11.38\"W x 11.32\"H 24 lbs. 24 lbs. Custom configurations, individual connectors and interconnecting cable assemblies available. 32

WE DELIVER THE POWERTM100 Amp 3 Phase Pagoda to Duplex Receptacles PowerHOUSE™ Portable Distribution BoxesCatalog Number: DB100A-A401520 Features & Benefits:(for other configurations, see table below) • Heavy-duty molded rubber enclosure is fully insulated and resistant to shock, impact and corrosionDescription: • Circuit breakers are mounted under hinged lid for enhanced100 Amp, 3 Phase, 4 Pole, 5 Wire, 120/208Y VAC, Pagoda protectionEnclosure, (1) set of (5) 16 Series Cam-type color-coded panelmount inlets to (15) NEMA 5-20, 20 Amp duplex receptacles, • Stackable and compact for easy storage and convenientNEMA 1 Indoor or NEMA 3R Weather Resistant. Weather resistant portabilityversion available with (12) GFCI duplex receptacles. • Elevated base keeps receptacles above ground levelApplication: TYPE 1 Indoor orThis PowerHOUSE™ Pagoda portable distribution box is TYPE 3Rextremely versatile, and can be fed from a generator or panel.Rated for indoor use, this box can accept up to (30) NEMA 5-20,20 Amp Edison cords (24 on GFCI version) to power portablepower tools, computers, vending machines and sound systems.Specifications & Ordering InformationCatalog Number DB100NP-AQQ-S3 DB100A-A401520 DB100NP-ABB-S3 100 Amp, 3 Phase (H,H,H,N,G), 4 Pole, 100 Amp, 3 Phase (H,H,H,N,G), 4 Pole, 100 Amp, 3 Phase (H,H,H,N,G), 4 Pole,Rating 5 Wire, 120/208Y VAC 5 Wire, 120/208Y VAC 5 Wire, 120/208Y VAC cULus Listed TYPE 3R cULus Listed TYPE 1 Indoor cULus Listed TYPE 3RAgency ListingEnvironmental NEMA 3R Weather Resistant NEMA 1 Indoor NEMA 3R Weather ResistantRating (1) set of (5) 16 Series Cam-type color- (1) set of (5) 16 Series Cam-type color- (1) set of (5) 16 Series Cam-type color-Input coded panel mount inlets coded panel mount inlets coded panel mount inletsOutput (12) NEMA 5-20, 20 Amp, 2 Pole, 3 Wire, (15) NEMA 5-20, 20 Amp, 2 Pole, 3 Wire, (15) NEMA 5-20, 20 Amp, 2 Pole, 3 Wire, 120 VAC GFCI duplex receptacles 120 VAC duplex receptacles 120 VAC, duplex receptaclesFeed ThruOvercurrent None None NoneProtection (12) 20 Amp, Single Pole branch-rated (15) 20 Amp, Single Pole branch-rated (15) 20 Amp, Single Pole branch-ratedEnclosure TypeDimensions circuit breakers circuit breakers circuit breakersApproximate Pagoda Pagoda PagodaWeight 14.25\"L x 14.25\"W x 14.15\"H 14.25\"L x 14.25\"W x 14.15\"H 114.25\"L x 14.25\"W x 14.15\"H 32 lbs. 32 lbs. 32 lbs. Custom configurations, individual connectors and interconnecting cable assemblies available. 33

WE DELIVER THE POWERTM PowerHOUSE™200 Amp 3 Phase Motion Picture Box, Feed Thru Portable Distribution BoxesAlso known as the 600 Amp Box in the Film Industry TYPE 1 Indoor Application:Catalog Number: DB200A-A4061FT This box provides 100 Amp stage pin receptacles for high power lighting effects, or to distribute power further down stream. The(for other configurations, see table below) feed thru feature allows multiple boxes to be placed along the same feed.Description: Features & Benefits:200 Amp, 3 Phase, 4 Pole, 5 Wire, 120/208Y VAC, (1) set of (5)16 Series Cam-type color-coded panel mount inlets (available in • Heavy-duty molded rubber enclosure is fully insulated andreverse ground, or reverse ground and neutral configurations) to resistant to shock, impact and corrosion(6) 100 Amp stage pin receptacles and (2) NEMA 5-20, 20 Ampduplex receptacles, Feed Thru, NEMA 1 Indoor • Circuit breakers are mounted under hinged lid for enhanced protection • Stackable and compact for easy storage and convenient portability • Elevated base keeps receptacles above ground level • Reverse neutral and ground options help prevent mis-mating for enhanced safetySpecifications & Ordering InformationCatalog Number DB200A-A4061FT DB200A-A4061FT-RGN DB200A-A4061FT-RGRating 200 Amp, 3 Phase (H,H,H,N,G), 200 Amp, 3 Phase (H,H,H, Reverse N, 200 Amp, 3 Phase (H,H,H,N, Reverse G), 4 Pole, 5 Wire, 120/208Y VAC Reverse G),4 Pole, 5 Wire 120/208Y VAC 4 Pole, 5 Wire, 120/208Y VACEnvironmental NEMA 1 Indoor NEMA 1 Indoor NEMA 1 IndoorRatingInput (1) set of (5) 16 Series Cam-type color- (1) set of (5) 16 Series Cam-type color- (1) set of (5) 16 Series Cam-type color- coded panel mount inlets coded panel mount inlets with reverse coded panel mount inlets with reverse neutral and ground groundOutput (6) 100 Amp, 2 Pole, 3 Wire, 120 VAC stage (6) 100 Amp, 2 Pole, 3 Wire, 120 VAC stage (6) 100 Amp, 2 Pole, 3 Wire, 120 VAC stage pin receptacles pin receptacles pin receptacles (2) NEMA 5-20, 20 Amp, 2 Pole, 3 Wire, (2) NEMA 5-20, 20 Amp, 2 Pole, 3 Wire, (2) NEMA 5-20, 20 Amp, 2 Pole, 3 Wire, 120 VAC duplex receptacles 120 VAC duplex receptacles 120 VAC duplex receptaclesFeed Thru (1) set of (5) 16 Series Cam-type color- (1) set of (5) 16 Series Cam-type color- (1) set of (5) 16 Series Cam-type color- coded panel mount receptacles coded panel mount receptacles with coded panel mount receptacles with reverse neutral and ground reverse groundOvercurrent (6) 100 Amp, Single Pole branch-rated (6) 100 Amp, Single Pole branch-rated (6) 100 Amp, Single Pole branch-ratedProtection circuit breakers circuit breakers circuit breakers (2) 20 Amp, Single Pole branch-rated circuit (2) 20 Amp, Single Pole branch-rated circuit (2) 20 Amp, Single Pole branch-rated circuit breakers breakers breakersEnclosure Pagoda Pagoda PagodaDimensions 14.25\"L x 14.25\"W x 14.15\"H 14.25\"L x 14.25\"W x 14.15\"H 14.25\"L x 14.25\"W x 14.15\"HApproximate 45 lbs. 45 lbs. 45 lbs.Weight Custom configurations, individual connectors and interconnecting cable assemblies available. 34

WE DELIVER THE POWERTM PowerHOUSE™Load Master® Series Portable Distribution BoxesAdjustable Breaker Box Application: Provides overcurrent protection and a main disconnect for portable power distribution systems. The current trip setting is adjustable, allowing it to protect a variety of systems with different cable sizes. Features & Benefits: • Adjustable trip setting allows the box to protect a variety of systems with different cable sizes • Adjustable electronic breakers will not nuisance trip under TYPE 3R high ambient temperatures • Heavy-duty molded rubber enclosure is fully insulated andDescription: resistant to shock, impact and corrosion160-400 Amp or 100-250 Amp Variable Output Box, 3 Phase, 4 • Circuit breakers are mounted under hinged lid for enhancedPole, 5 Wire, 120/208 VAC, Pagoda Enclosure, (1) set of (5) 16 protectionSeries Cam-type color-coded panel mount inlets to (1) set of (5) 16 • Stackable and compact for easy storage and convenientSeries Cam-type color-coded panel mount outlets and (1) NEMA portability5-20, 20 Amp duplex receptacle, NEMA 3R Weather Resistant • Elevated base keeps receptacles above ground levelSpecifications & Ordering InformationCatalog Number DB400LP-AWB-S3 DB250LP-AWB-S3Rating 160-400 Amp variable output, 3 Phase (H,H,H,N,G), 100-250 Amp variable output, 3 Phase (H,H,H,N,G), 4 Pole, 5 Wire, 120/208Y VAC 4 Pole, 5 Wire, 120/208Y VACEnvironmentalRating NEMA 3R Weather Resistant NEMA 3R Weather ResistantInput (1) Set of (5) 16 Series Cam-type color-coded panel mount inlets (1) Set of (5) 16 Series Cam-type color-coded panel mount inletsOutput (1) Set of (5) 16 Series Cam-type color-coded panel mount outlets (1) Set of (5) 16 Series Cam-type color-coded panel mount outlets with variable output with variable output (1) NEMA 5-20, 20 Amp, 2 Pole, 3 Wire, 120 VAC duplex receptacle (1) NEMA 5-20, 20 Amp, 2 Pole, 3 Wire, 120 VAC duplex receptacleFeed Thru None NoneOvercurrent (1) 400 Amp adjustable electronic breaker, 160 Amp - 400 Amp (1) 250 Amp adjustable electronic breaker 100 Amp - 250 AmpProtection (1) 20 Amp, Single Pole branch-rated circuit breaker (1) 20 Amp, Single Pole, 120/240 VAC branch-rated circuit breakerEnclosure Pagoda Pagoda 14.25\"L x 14.25\"W x 14.15\"H 14.25\"L x 14.25\"W x 14.15\"HDimensions 44 lbs. 44 lbs.ApproximateWeightAvailable in 480 VAC and 600 VAC versions. Contact a Lex Products sales representative. Custom configurations, individual connectors and interconnecting cable assemblies available. 35

WE DELIVER THE POWERTM PowerHOUSE™400 Amp 3 Phase Cam-Type Splitter Box Portable Distribution BoxesSpider BoxCatalog Number: DB400BP-WWW-S3 Features & Benefits:Description: • High-density polyethylene (HDPE) top, bottom and sides provide superior impact, weather and shock resistance400 Amp, 3 Phase, 4 Pole, 5 Wire, 120/208Y VAC, TurtleEnclosure, (1) set of (5) 16 Series Cam-type color-coded panel • Safe and expedient means of distributing 400 Amp,mount inlets to (5) sets of (5) 16 Series Cam-type color-coded 3 Phase Cam-type cable runspanel mount outlets, NEMA 1 Indoor • Compact for convenient portabilityApplication: Specifications:This box is fed by a generator or panel and splits off five separatesets of 5-wire Cam-type receptacles. It allows multiple film Rating: 400 Amp, 3 Phase (H,H,H,N,G), 4 Pole, 5 Wire,shoots to be set up, and then can power the individual shoots on 120/208Y VACan as-needed basis throughout the day. The runs are not used Environmental Rating: NEMA 1 Indoorsimultaneously and there is no overcurrent protection. Input: (1) Set of (5) 16 Series Cam-type color-coded panel mount inlets Output: (5) Sets of (5) 16 Series Cam-type color-coded panel mount outlets Feed Thru: None Overcurrent Protection: None Enclosure Type: Turtle Dimensions: 20.5\"L x 11\"W x 18\"H Weight: 56 lbs.Custom configurations, individual connectors and interconnecting cable assemblies available. 36

WE DELIVER THE POWERTM PowerHOUSE™400 Amp 3 Phase Motion Picture Box, Feed Thru Portable Distribution BoxesAlso known as the 1200 Amp Box in the Film Industry TYPE 1 Indoor Specifications:Catalog Number: DB400N2J6BC3BD-H1 Rating: 400 Amp, 3 Phase (H,H,H,N,G), 4 Pole, 5 Wire, 120/280Y VACDescription: Environmental Rating: NEMA 1 Indoor400 Amp, 3 Phase, 4 Pole, 5 Wire, 120/208Y VAC, Power StationEnclosure, (1) set of (5) 16 Series Cam-type color-coded panel Input:mount inlets to (3) 100 Amp, 220 VAC stage pin receptacles, (6) (1) set of (5) 16 Series Cam-type color-coded panel mount inlets100 Amp, 120 VAC stage pin receptacles and (1) NEMA 5-20, 20Amp duplex receptacle, Feed Thru, NEMA 1 Indoor Output: (3) 100 Amp, 2 Pole, 3 Wire, 220 VAC stage pin receptaclesApplication: (6) 100 Amp, 2 Pole, 3 Wire, 120 VAC stage pin receptacles (1) NEMA 5-20, 20 Amp, 2 Pole, 3 Wire duplex receptacleDistributes power to large 120 VAC and 220 VAC lighting fixtureson sets or on location shoots. A duplex receptacle Feed Thru:is provided for convenience use. (1) set of (5) 16 Series Cam-type color-coded panel mount outletsFeatures & Benefits: Overcurrent Protection: (3) 100 Amp, Single Pole branch-rated circuit breakers• Provides a variety of stage pin receptacles for powering (6) 100 Amp, 2 Pole branch-rated circuit breakers multiple lights (1) 20 Amp, Single Pole branch-rated circuit breaker• Heavy-duty molded rubber enclosure is fully insulated and Enclosure Type: Power Station resistant to shock, impact, and corrosion Dimensions: 27.5\"L x 18.5\"W x 18\"H• Circuit breakers are mounted under hinged lid for enhanced protection Weight: 90 lbs.• Stackable and compact for easy storage and convenient portability• Elevated base keeps receptacles above ground levelCustom configurations, individual connectors and interconnecting cable assemblies available. 37

WE DELIVER THE POWERTM 6kW, 12kW and 24kW Portable Single Dimmers Unique portable dimming solutions for location, stage or studio applicationsFeatures & Benefits:• Lightweight and compact• Panel mount stage pin connectors for input and output• LED indicators show status of circuit breakers and output voltage• Analog controls retain pre-heat status, dimmer level, operating mode and DMX512 address through power outage• User selectable dim or non-dim operation• Lamp warmer function sets pre-heat to 5%• Status Quo maintains last-look in case of data loss• Separate LEDs indicate presence of power input, power output and DMX512-A• Metal enclosure construction for durability• All connections and controls fully protected to help deliver years of trouble-free serviceSpecifications & Ordering InformationCatalog No. FD2-6KW FD2-12KW / FD2-C-12KW FD2-24KW / FD2-C-24KWDescription Single channel 6,000 watt, 120 VAC, Single channel 12,000 watt, 120 VAC, Single channel 24,000 watt, 240 VAC, portable dimmer/relay portable dimmer/relay portable dimmer/relayInput Voltage Range 95-130 VAC 95-130 VAC 190 - 240 VACInput/Output Connectors 60 Amp, 2 Pole, 3 Wire, 120 VAC 100 Amp, 2 Pole, 3 Wire, 120 VAC 100 Amp, 2 Pole, 3 Wire, 240 VAC stage pin (ANSI E1.24 5T60) stage pin (ANSI E1.24 5T100) stage pin (ANSI E1.24 6T100)Minimum Load 50 W 50 W 50 WMaximum Load 6 kW 12 kW 24 kWOvercurrent Protection Single Pole, 50 Amp magnetic, branch- Single Pole, 100 Amp magnetic, branch- 2 Pole, 100 Amp magnetic, branch-rated rated circuit breaker rated circuit breaker circuit breakerCooling Low RPM Fans Low RPM Fans Low RPM Fans (very low noise) (very low noise) (very low noise)Weight 24 pounds (10.89kg) 24 pounds (10.89kg) 24 pounds (10.89kg)Dimensions 12.00” W x 16.00” D x 7.00” H 12.00” W x 16.00” D x 7.00” H 12.00” W x 16.00” D x 7.00” H 30.46 cm W x 40.6 cm D x 17.78 cm H 30.46 cm W x 40.6 cm D x 17.78 cm H 30.46 cm W x 40.6 cm D x 17.78 cm H Note: Canadian versions available. Custom configurations, individual connectors and interconnecting cable assemblies available. 38

WE DELIVER THE POWERTMSlim Dimmer PlusCompact, Full Featured 1.8kW DimmerLDP1.8K LDT1.8KCatalog Number: LDP1.8K / LDT1.8K Specifications:Description: Rating: 15 Amp, Single Phase, 2 Pole, 3 Wire, 120 VAC Input: (1) NEMA 5-15, 15 A plug on an 18 inch 12/3 SJOWThe Slim Dimmer Plus is a compact, feature-rich 1800W dimmer, cablewhich employs DMX512 communication. This dimmer can Output: (1) NEMA 5-15, 15 A receptaclebe controlled locally and used as a part of a location lighting Minumum/Maximum Load: 60W/1800 Wkit to balance the lighting from several sources. It can also be Overcurrent Protection: 15 Amp push to reset circuit breakercontrolled from a lighting console using DMX, and used to Dimensions: 7.3\"L x 4.15\"W x 2.5\"Haugment an entertainment lighting system. Weight: 2.1 lbsApplication: Accessories/Catalog Number/Description:Use one or more Slim Dimmer Plus to balance location lighting Hanging female 1/4\"-20 threaded insert accommodates a varietyor to dim entertainment lighting. The Slim Dimmer can also of accessories.be used in last minute situations where “one more dimmer” is 04-160-A01: 1/4\" -20 to 3/8\"-16 Male to Male Thread Adapterneeded. 04-160-A02: 1/4\" -20 to 1/2\"-13 Male to Male Thread Adapter 04-160-A11: C-Clamp with Thread Adapter to 1/4\"-20 ThreadFeatures & Benefits:• Control using both DMX and a front panel fader for maximum versatility• Large display showing dimmer level and DMX address for easy setup• Can configure as a DMX controlled electronic non-dim to switch loads on and off remotely• Durable, compact construction for long life and reliability• Variety of mounting options available with optional hardwareNote: The Slim Dimmer Plus 1.8kW is a compact dimmer with no output filtering which may result in some lamp noise depending on the lamp being dimmed. Custom configurations, individual connectors and interconnecting cable assemblies available. 39

WE DELIVER THE POWERTM Custom Rolling Distribution RacksIdeal for touring applications where power requirementschange frequently, these high-quality, durable racks canfeature a range of input, output and circuit breaker options.Features & Benefits:• Custom rack sizes, colors• “Snap-in” latches allow quick access and closure.• High-density panels with recessed hardware and aluminum frame.• Custom circuit numbering and logos on rack panels are available• All panels have standard engraving for sequential device numbering, power ratings and safety notices.Rack Specifications Panel Specifications1. Rack shall be constructed using vertical and 1. Panels shall be fabricated from 0.090” Aluminum. horizontal rails of extruded 5052-H32 aluminum. 2. Finish shall be anodized black.2. Finish shall be anodized black. 3. Panel top and bottom edges shall be flanged 1.0”.3. Corners shall be cast GB Aluminum 102 Alloy. 4. Panels shall be punched to accommodate NEMA wiring4. Rack rail shall be constructed for mounting of devices, XLR data devices, Cam-type devices, pin & sleeve, 19” wide (482.6 mm) rack panels in vertical configurations LSC19 and stage pin devices, LED indicators and digital according to EIA standard rack unit spacing of 1U = 1.75” meters. (44.45 mm). 5. Panels shall be laser engraved with device sequence5. Rack frame shall be constructed to accomodate machined, numbering, input/output power ratings, power connection ½” and ¾” high density polymer panels (HDPE). These panels instructions and safety warnings. shall be affixed to the frame in the top, bottom and two side positions.6. Casters shall be 3½” (89 mm), 250 lb. (113 kg) capacity with a See Our PowerRACKTM Brochure for part numbers swivel radius of 2.906” (73.8 mm). and additional configuration details.Custom configurations, individual connectors and interconnecting cable assemblies available. 40

WE DELIVER THE POWERTM Enclosed Rack Mount Power DistributionLex Products’ PowerRACK™ Enclosed Rack Mount PowerDistribution modules allow convenience receptacles to be added tostandard EIA (Electronics Industries Alliance) 19-inch permanentor portable racks. Modules are ETL Listed to UL Standards and areavailable in 1, 2 and 3 rack unit heights.Nineteen different configurations offer many input and outputoptions, and make the modules exceptionally flexible for shiftingpower requirements. Typical applications include powering audioand lighting equipment. Convenience ReceptaclesCompact and fully Feed Thru Option Indicator Features & Benefitsenclosed Lights • Product range includes a variety of connectors to meet the ETL Listed changing needs of entertainment venues, including Neutrik powerCONs for the growing use of LED lights • ETL Listed for US and Canada, tested to UL Standards • Aluminum construction with anodized finish is lightweight for portability and durablility, while ensuring years of service • Modules are fully enclosed for easy handling and installation • Indicator lights and laser etched labels enable easy circuit identification • Suitable for Lex Products’ PowerRACK™ Rolling Distribution Racks or any standard 19” rack, permanent or portable See Our PowerRACKTM Brochure for part numbers and additional configuration details. Custom configurations, individual connectors and interconnecting cable assemblies available. 41

WE DELIVER THE POWERTMPowerRAMP® Cable Protectors PowerHOUSE®™Crossovers, 45˚ Left and Right Turn Units and End Boots Portable Distribution Boxes Features & Benefits: • Heavy duty, non-conductive polyurethane construction provides safe crossing for pedestrians and vehicles while protecting electrical cables and hose lines • Rugged industry standard connectors with exclusive “slip notch” friction release design provides easy mating and un- mating • Mates with major cable protector brands and products • 5-channel design can accommodate up to 1.25 inch diameter cables and hoses • 1.625 inch wide center channel allows for up to #2 AWG 5-wire banded sets • Exclusive tread design provides excellent traction • Hinged lid provides easy access for insertion and removal of cables and hoses • Made from UV stabilized material for prolonged use in direct sunlight • High-visibility blue lid and black base • Company name or logo can be molded into lid of Crossover Cable Protector for easy identificationDescription: Typical Application:Heavy duty, 5-channel, modular cable protector with hinged Protects cables and hoses from damage when run across roads,lid and rugged industry standard connectors can be easily parking lots, sidewalks and pathways, providing safe crossing forinterconnected to protect cables of any length or mate with pedestrian and vehicle traffic.45˚ left and right turn units and end boots to provide alternateconfigurations for design flexibility.Catalog No. Descriptions (A) Length (B) Width (C) Height (D) Channel Height (E) Channel Width Weight ChannelsPRC-5* 5-Channel 35.5 in./901.7 mm 19.75 in./634 mm 2 in./51 mm (5) 1.25 in./32 mm (4) 1.25 in./32 mm 27 lbs./12.2 5 Crossover (1) 1.625 in./41.3 mm kgPREB-5 5-Channel Male: 3.75 19.75 in./634 mm 2 in./51 mm (5) 1.25 in./32 mm (4) 1.25 in./32 mm Male: 2.5 5 End Boots in./95.25 mm (1) 1.625 in./41.3 mm lbs./1.1 kg (Pair M/F) Female: 7 in./177.8 mm Female: 4.5 lbs./2 kgPRTL-5* 5-Channel 25 in./634 mm 19.75 in./634 mm 2 in./51 mm (5) 1.25 in./32 mm (4) 1.25 in./32 mm 15.5 lbs./7 kg 5PRTR-5* 45˚ Left Turn (1) 1.625 in./41.3 mm 5-Channel 25 in./634 mm 19.75 in./634 mm 2 in./51 mm (5) 1.25 in./32 mm (4) 1.25 in./32 mm 15.5 lbs./7 kg 5 45˚ Right Turn (1) 1.625 in./41.3 mm* - Add “c-oBlKor”saafvtearilacabtlea.loCgonnusumltbCeyuor sufotrorfmabclatcocorknylfiirdegpaurnreadsteibonlnatacskt,ivibneadsfioevridduetaalilcso.nnectors and interconnecting cable assemblies available.Custom 42

PowerPARTS™ Wiring Devices PowerPARTS™ Cable Accessories Lex Products offers a full line of PowerPARTS™ connectors and cable accessories, including stage pin, 19 pin, Cam-type connectors, cable protectors and more. The PowerPARTS™ line of connectors and cable accessories includes the proprietary Lex Loc™, the industry’s first cage clamp NEMA wiring device, which features unique terminals that overcome potential causes of device failure by using spring pressure that automatically adjusts to help prevent shifting wire strands. Contact Your LEX Representative for a detailed list of part numbers and pricing. Call 1-800-643-4460 or e-mail [email protected]

WE DELIVER THE POWERTMLex Products EverGrip® Cable Retrofit Service ProgramLex Products EverGrip Cable Retrofit Service Program Overview:EverGrip cable retrofits for 19-pin multi-cable, 7 and 14 pin motor control and ARRI ballastextensions include the removal of original connectors, and the installation of clear heatshrink to each cable end. New molded connectors are then pinned to the cable ends and acontinuity test is performed prior to the EverGrip overmold procedure. After connectors areovermolded, the cable receives a final continuity test.Catalog Number Description Parts ReplacedEG-RETROFIT Retrofit a pair of EverGrip LSC19 connectors to customers’ existing Replace male and female connectors withEG7P-RETROFIT 12/14,12/18, 14/14 or 16/18 cables* overmolded LSC19 connectorsEG14P-RETROFIT Retrofit a pair of EverGrip 7 pin quarter turn motor control connectors to Replace male and female connectors withEG7PSX-RETROFIT customers’ existing 16 AWG/7 conductor cable overmolded 7 pin quarter turn connectorsEG-RETROFIT-ARRI 575WEG-RETROFIT-ARRI 2.5KW Retrofit a pair of EverGrip 14 pin quarter turn motor control connectors to Replace male and female connectors withEG-RETROFIT-ARRI 6KWEG-RETROFIT-ARRI 12KW customers’ existing 16 AWG/7 conductor cable overmolded 14 pin quarter turn connectors Retrofit a pair of EverGrip 7 pin overmolded Socapex compatible Replace existing male and female connectors with connectors to customers’ existing 16 AWG/7 conductor cable or heavy- overmolded 7 pin Socapex compatible connectors duty 14 AWG/7 conductor cable Retrofit a pair of EverGrip 575W ballast connectors to customers’ Replace male and female connectors with existing 14 AWG/7 conductor SOOW cable* overmolded 575W ballast connectors Retrofit a pair of EverGrip 2.5kW ballast connectors to customers’ Replace male and female connectors with existing 12 AWG/7 conductor SOOW cable* overmolded 2.5kW ballast connectors Retrofit a pair of EverGrip 6kW ballast connectors to customers’ existing Replace male and female connectors with 4/2, 8/1, 14/4 TPE cable* overmolded 6kW ballast connectors Retrofit a pair of EverGrip 12kW ballast connectors to customers’ existing Replace male and female connectors with 4/2, 8/1, 14/4 TPE cable* overmolded 12kW ballast connectorsRetrofit Cable Standard Lead Times (business days) 1-15 16-30 31-50 51-100 5 Days 6 Days 7 Days 8 DaysOrder QuantityStandard Lead TimesEverGrip Cable Retrofit Ordering Procedure:• Contact a Lex Products sales representative at 800.643.4460 for pricing, to request a repair merchandise authorization (RMA) and lead time information.• A purchase order and RMA are required to complete order processing.• Customer is responsible for inbound and outbound freight charges.• See www.lexproducts.com/cs/sales_policy for warranty details.*Lex Products EverGrip molded 19 pin cable assemblies and ARRI ballast extensions feature a 5-year warranty that covers molded connector failureresulting from pushed pins, broken conductors and broken ground rings within the connector, or other defects of material or workmanship.Custom configurations, individual connectors and interconnecting cable assemblies available. 44

WE DELIVER THE POWERTMLex Products Cable Repair Service Program Lex Products Standard Cable Repair Overview: Standard cable repair services include inspection of the cable jacket and conductors for cuts, as well as a continuity test. Repairs include heavy wall heat shrink application for jacket cuts, replacement of all connectors and terminals, and tape and label replacement (if replaceable). Clear heat shrink is installed to each cable end. All cables receive a final continuity test. Standard cable repair services carry a 1-year limited warranty.Catalog Number Description Parts ReplacedRS MULTI-CABLE Repair service 19 pin multi-cable Male and female 19 pin connectorsRS BREAK IN/OUT Repair service break-in/break-out Male and female 19 pin connectors and all ouputRS CAM EXTENSION Repair service Cam feeder extension 1/0-4/0 connectorsRS BANDED CAM EXTENSION Repair service feeder banded Cam extension Male and female 1/0-4/0 Cam connectors (black)RS CAM FEMALE TAIL Repair service female Cam tails 1/0-4/0 Male and female Cam connectors #2 all colors andRS CAM MALE TAIL Repair service male Cam tails 1/0-4/0 banding if neededRS CAM FEMALE TAIL RT Repair service female Cam tails 1/0-4/0 w/ ring terminal Female Cam 1/0-4/0 Cam connector (black) Male Cam 1/0-4/0 Cam connector (black)RS CAM MALE TAIL RT Repair service male Cam tails 1/0-4/0 w/ ring terminal Female Cam 1/0-4/0 Cam connector (black) & ring terminal PN 4-0-13R1RS 7 PIN QTR TURN CABLE Repair service 7 pin quarter-turn motor control cable Male Cam 1/0-4/0 Cam connector (black) & ringRS 14 PIN QTR TURN CABLE Repair service 14 pin quarter-turn motor control cable terminal PN 4-0-13R1RS QUAD STRINGER Repair service quad stringer 7 pin quarter turn male and female connectors 14 pin quarter turn male and female connectors All duplexes, all GFCIs and all covers; plugs, boxes and connectors if neededCable Repair Ordering Procedure:• Contact a Lex Products sales representative at 800.643.4460 for pricing, to request a repair merchandise authorization (RMA) and lead time information.• A purchase order and RMA are required to complete order processing.• Some repairs may deviate from standard procedures and may require an additional evaluation repair process at an additional cost. Customer will be contacted for authorization.• Customer is responsible for inbound and outbound freight charges.• See www.lexproducts.com/cs/sales_policy for warranty details.Custom configurations, individual connectors and interconnecting cable assemblies available. 45

WE DELIVER THE POWERTMCable Labeling ServicesLex Products offers a variety of additional services to improve cable identification, inventory management, and deter theft with cablelabeling. PowerTAGS™ - Cable Markers Self-Laminating Labels Brightly colored, durable thermoplastic cable markers allowing Extremely durable custom, self-laminating labels under clear heat for easy identification of cable assemblies from a distance. RFID shrink. chips, barcodes, or custom labels may be inserted behind a clear window insert for added security and inventory management. Label Material: Translucent vinyl Features & Benefits: Printing: Black thermal transfer • Ruggedly designed to withstand high impact and extreme Label Printable Area: temperatures • Built-in clear window allows for barcodes, custom labeling, 2\" wide x 1-1/2\" high: Feeder cable, multi-cable (6 cct.), Stage pin extensions, NEMA extensions, speakCON assemblies, Fly cable, or customer supplied RFID chips DataSnake, Cat5 snake • Rope ties may be added for bundling cable coils Available Colors: 2\" wide x 1/2\" high: DMX512 cable, color changer cable, RFU • White cable, Cat5 cable • Red • Orange Background Colors: • Yellow • White • Blue • Red • Custom Colors Are Available • Orange • Yellow Available for a variety of PowerFLEXTM cables, ask your LEX Sale • Green representative for more details. • BluePowerTAGS™ - Cable Markers • Violet Temperature Range: -60F to +200F Vinyl Tape Extremely durable vinyl tape under clear heat shrink. Label Material: 1/2 inch wide opaque vinyl Printing: N/A Tape Colors: • White • Red • Orange • Yellow • Green • Blue • Violet Temperature Range: -60F to +200F 46

WE DELIVER THE POWERTMGlossary of Portable Cord TypesThermoset (rubber) material hardens or \"sets\" under Thermoplastic (plastic) material softens when heated direct application of heat (a process called curing), and once and becomes firm upon cooling. It is not as durable or as it sets, is not able to be re-softened by heating. Thermoset is flexible as thermoset material, but is much lighter in weight a much more durable compound than thermoplastic. and offers excellent low temperature resistance. Thermoset cords include the following types: Thermoplastic cords include the following types:SOOW (Service, Oil resistant jacket, Oil resistant insulation, SEOW/STW (Service, Elastomer jacket, Oil resistant Weather resistant): The toughest Thermoset portable jacket, Weather resistant): Features a Thermoplastic cord available, this premium portable cord withstands the Elastomer jacket and insulation, which offer exceptional low most demanding environments and temperature extremes. temperature capabilities. SEOW has an oil resistant jacket SOOW is oil, chemical, ozone and acid resistant and and is water resistant and extremely lightweight. SEOW also resists tears, cuts and abrasions, and is completely is suitable for outdoor use in industrial applications with water submersible and flame retardant. SOOW can be construction tools and other electrical equipment, but is not used for various indoor and outdoor applications, such as recommended for contact with hot surfaces. SEOW meets industrial equipment, heavy tools, motor and welding leads, CSA approval for outdoor use as STW. power extensions, portable machinery, sound equipment, portable stage lights, marine dockside power and in mining STOW/STW (Service, Thermoplastic jacket, Oil resistant applications. SOOW meets CSA approval for outdoor use. jacket, Weather resistant): Hard service thermoplastic cordSOOW Portable Cord, SOOW Portable which will deform under extreme pressure or heat. STOW Control Cable (Service, Oil resistant jacket, Oil features an oil resistant jacket and is for indoor/outdoor use with heavy tools, equipment, portable lights and power resistant insulation, Weather resistant): Has a tough, flexible extensions. STOW meets CSA approval for outdoor use as Thermoset rubber jacket which is abrasion, sunlight, ozone, STW. oil and chemical resistant. SOOW is also water submersible and flame retardant. SOOW is designed for indoor and STO (Service, Thermoplastic, Oil resistant jacket): same as outdoor use with industrial equipment, heavy tools, battery chargers, portable lights and power extensions. SOOW STOW but for indoor use only. meets CSA APPROVAL for outdoor use. STW (Service, Thermoplastic, Weather resistant): same asSJ (Service, Junior): Junior service cord (300V). SJ has an all STOW but jacket is not oil resistant. STW meets CSA rubber construction, remains flexible at low temperatures, approval for outdoor use. and is designed for indoor use with portable tools, equipment and motors. SVT (Service, Vacuum, Thermoplastic): same as SV but withSV (Service, Vacuum): Junior light-duty vacuum cord (300V). Thermoplastic insulation and jacket. SV remains flexible at low temperatures and is for use with SPT-1 & 2 (Service, Parallel, Thermoplastic): PVC insulated, vacuum cleaners and other light-duty equipment. extra flexible parallel cord for use in household appliances,SVO (Service, Vacuum, Oil resistant jacket): same as SV, but including clocks, fans, radios, and most often, SPT-2 in lamps. jacket is oil resistant. SPT-1.5 (Service, Parallel Thermoplastic): AWM Style 20288, PVC insulated, extra flexible parallel cord for use as internal wiring of appliances or can be woven through links of chains (suspended fixtures).Lex Products • www.lexproducts.com • 1.800.643.4460 47

WE DELIVER THE POWERTMGenerator KVA Rating to Amperage Conversion Chart80% Power FactorkV•A kW 208V 220V 240V 380V 440V 480V 600V 2400PVower3H30O0UVSE™4160V6.3 5 17.5 16.5 15.2 9.6 8.3 7.6 6.1 Portable Distribution Boxes9.4 7.5 26.1 24.7 22.6 14.3 12.3 11.3 9.112.5 10 34.7 33 30.1 19.2 16.6 15.1 1218.7 15 52 49.5 45 28.8 24.9 22.5 1825 20 69.5 66 60.2 38.4 33.2 30.1 24 6 4.4 3.531.3 25 87 82.5 75.5 48 41.5 37.8 30 7.5 5.5 4.437.5 30 104 99 90.3 57.6 49.8 45.2 36 9.1 6.6 5.250 40 139 132 120 77 66.5 60 48 12.1 8.8 762.5 50 173 165 152 96 83 76 61 15.1 10.9 8.775 60 208 198 181 115 99.5 91 72 18.1 13.1 10.593.8 75 261 247 226 143 123 113 90 22.6 16.4 13100 80 278 264 240 154 133 120 96 24.1 17.6 13.9125 100 347 330 301 192 166 150 120 30 21.8 17.5156 125 433 413 375 240 208 188 150 38 27.3 22187 150 520 495 450 288 249 225 180 45 33 26219 175 608 577 527 335 289 264 211 53 38 31250 200 694 660 601 384 332 301 241 60 44 35312 250 866 825 751 480 415 376 300 75 55 43375 300 1040 990 903 576 498 451 361 90 66 52438 650 1220 1155 1053 672 581 527 422 105 77 61500 400 1390 1320 1203 770 665 602 481 120 88 69625 500 1735 1650 1504 960 830 752 602 150 109 87750 600 2080 1980 1803 1150 996 902 721 180 131 104875 700 2430 2310 2104 1344 1274 1052 842 210 153 1211000 800 2780 2640 2405 1540 1330 1203 962 241 176 1391125 900 3120 2970 2709 1730 1495 1354 1082 271 197 1561250 1000 3470 3300 3009 1920 1660 1504 1202 301 218 1741563 1250 4350 4130 3740 2400 2080 1885 1503 376 273 2181875 1500 5205 4950 4520 2880 2490 2260 1805 452 327 2612188 1750 5280 3350 2890 2640 2106 528 380 3042500 2000 6020 3840 3320 3015 2405 602 436 3482812 2250 6780 4320 3735 3400 2710 678 491 3923125 2500 7520 4800 4160 3740 3005 752 546 4353750 3000 9040 5760 4980 4525 3610 904 654 5224375 6500 Lex Products • www.lexproducts.com • 1.800.643.4460 10550 6700 5780 5285 4220 1055 760 6105000 4000 12040 7680 6640 6035 4810 1204 872 695 Custom configurations, individual connectors and interconnecting cable assemblies available. 48

WE DELIVER THE POWERTMWire Conversion Chart PowerHOUSE™ Portable Distribution Boxes Wire Conversion Chart - American Wire Gauge to square millimeters AWG mm2 AWG mm2 AWG mm2 AWG mm2 30 0.05 18 0.75 6 16 4/0 120 28 0.08 17 1.0 4 25 300MCM 150 26 0.14 16 1.5 2 35 350MCM 185 24 0.25 14 2.5 1 50 500MCM 240 22 0.34 12 4.0 1/0 55 600MCM 300 21 0.38 10 6.0 2/0 70 750MCM 400 20 0.50 8 10 3/0 95 1000MCM 500NOTES: Custom configurations, individual connectors and interconnecting cable assemblies available. 49
